MiBoxer FUT037Z+ – 3 in 1 LED controller Zigbee 3.0

MiBoxer FUT037Z+ – LED controller

FUT037Z+ controls LED strips and lights in RGB, RGBW, RGB+CCT modes. Match the FUT037Z+ output configuration to the connected strip; control uses Zigbee 3.0 + RF 2.4 GHz.

Operating modes and use

• RGB: RGB strips with color and brightness adjustment.
• RGBW: RGBW strips, combining RGB colors with a separate white channel.
• RGB+CCT: RGB+CCT strips, combining color with tunable white.

Control

Zigbee 3.0 app control requires a Zigbee 3.0 gateway. The separate 2.4 GHz RF path accepts a paired MiBoxer remote.

Functions

• It relays the RF signal to another MiBoxer 2.4 GHz RF product, allowing a larger installation without a stronger transmitter.
• Mode synchronization keeps the same effect aligned across MiBoxer controllers paired with one remote.
• Selectable PWM frequency offers 250 Hz and 16 kHz modes for different installation requirements.
• DND mode helps prevent the light from switching on unexpectedly after power is restored.
• Music modes link selected lighting effects to sound.
• Lighting scenes can be selected or saved according to the device’s supported mode.
• Saturation adjustment changes color intensity while retaining the selected hue.
• Scheduling in the app sets lighting on and off times.

Compatible remotes

• RGB+CCT — controller in this mode: B4, B4-B, C5, C8, FUT089-B, FUT092, PUSH1, PUSH2
• RGBW — controller in this mode: B3-B, B3-W, FUT096-B

Technical specifications
