Mean Well PLC-30-15 29.7 W CC LED driver 3300 mA
Mean Well PLC-30-15 29.7 W CC LED driver 3300 mA – dimensions
Mean Well PLC-30-15 29.7 W CC LED driver 3300 mA – block diagram
Mean Well PLC-30-15 29.7 W CC LED driver 3300 mA – derating characteristic
Mean Well PLC-30-15 29.7 W CC LED driver 3300 mA – static characteristic
Mean Well PLC-30-15 29.7 W CC LED driver 3300 mA – power factor characteristic

Mean Well PLC-30-15 29.7W 3300mA 8.4–12V Constant Current (CC) LED driver

Minimum order quantity: 1. Order in multiples of 1.
89.42 PLN
Shipment in 8-10 working days
Constant Current (CC)
tm_PLC-30-15

Mean Well PLC-30-15 is a 29.7 W constant-current LED driver rated at 3300 mA, with a 8.4 V–12 V output-voltage region.

Quantity
Wishlist
Compare
  Delivery

1-3 dni (PL), 3-10 dni (non-PL)



Privacy Policy

  Return Policy

14 days

PLC-30-15 – full product specification

Mean Well PLC-30-15 is a PLC-30-series power supply rated at 29.7 W. The parameters below come from the exact official manufacturer datasheet.

Constant-current output

The model regulates 3300 mA across a 8.4 V–12 V DC voltage region.

Full technical specifications

Fully isolated enclosure Yes
Enclosure material plastic
Cooling free-air convection
Dimensions 160 × 46 × 30 mm
Document revision PLC-30-SPEC 2026-02-09
Typical efficiency 83.5 %
Input frequency 47–63 Hz
Input range 90–264 VAC / 127–370 VDC
Inrush current 35 A
Operating temperature -30–50 °C
Rated current 3300 mA
Operating mode Constant Current (CC)
CC-region maximum voltage 12 V
CC-region minimum voltage 8.4 V
Output voltage 12 V
Over-voltage protection range 10–14 V
Over-voltage protection Yes
Short-circuit protection Yes
Rated power 29.7 W
Manufacturer warranty 2 years
Weight 0.2 kg

Manufacturer datasheet

Complete source specification: official Mean Well datasheet.

Manufacturer information: Mean Well states that the PLC-30 series is not intended for LED applications in the EU and China; the manufacturer recommends the LPF, NPF, XLG, XLC or XLN series.

tm_PLC-30-15

Data sheet

Power supply type
Constant Current (CC)
Rated power [W]
20,1-30
Output Current of CC power supply [mA]
3300
CC operating window
8.4-12
Min. output voltage of led driver (CC)
8.4
Max. output voltage of led driver (CC)
12
Length [mm]
160
Width [mm]
46
Height/thickness [mm]
30
Warranty [years]
2
Input voltage [V]
90-264

Specific References

EAN13
4711287460222
MPN
PLC-30-15
