LED power supply Tridonic LC 200W 24V one4all NF SC EXC2 SP
LED power supply Tridonic LC 200W 24V one4all NF SC EXC2 SP is a constant voltage LED power supply rated up to 200 W. Values for individual settings are shown in the operating-point table. Documented interfaces and configuration methods: DALI, NFC, switchDIM.
LED power supply Tridonic LC 200W 24V one4all NF SC EXC2 SP
670.00 PLN
Shipment in 8-10 working days
zas_tridonic_28004438
LED power supply Tridonic LC 200W 24V one4all NF SC EXC2 SP is a constant voltage LED power supply rated up to 200 W. Values for individual settings are shown in the operating-point table. Documented interfaces and configuration methods: DALI, NFC, switchDIM.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
LED power supply Tridonic LC 200W 24V one4all NF SC EXC2 SP is a constant voltage LED power supply in the Driver LC 200W 24V o4a NF SC EXC2 family. Official article number 28004438 identifies this physical version.
Key properties
Common and exact-article specifications are kept separate from operating points. Power, LED voltage, efficiency and temperatures may depend on settings and load; the complete multi-row manufacturer data is shown below.
Technical specifications
| Manufacturer article number | 28004438 |
|---|---|
| Manufacturer family | Driver LC 200W 24V o4a NF SC EXC2 |
| Manufacturer product group | Compact drivers |
| Supply voltage | 220 – 240 V |
| AC voltage range | 198 – 264 V |
| DC voltage range | 176 – 280 V |
| Mains frequency | 0 / 50 / 60 Hz |
| Overvoltage protection | 320 V AC, 48 h |
| Typ. current (at 230 V, 50 Hz, full load) | 941 mA |
| Typ. current (220 V, 0 Hz, full load, XX % dimming level) | 165 mA |
| Leakage current | <0.5 mA |
| Typ. input current in no-load operation | 49 mA |
| Power Consumption | 213.7 W |
| Typ. power input on stand-by 230 V | <0.16 W |
| Typ. input power in no-load operation | 0.3 W |
| Output power range | 20–200 W |
| Typ. efficiency at 230 V | 94 % |
| λ over full operating range (max.) | 0.67–0.99C |
| THD at 230V, full load | <5.4 % |
| Starting time | <0.64 s; <0.34 s |
| Switchover time (AC/DC) | <0.14 s |
| Turn off time | <0.01 s |
| Output voltage tolerance | ±1 V |
| Output LF voltage ripple | ±5 % |
| Output P_ST_LM (at full load) | ≤1 |
| Output SVM (at full load) | ≤0.4 |
| Max. output voltage | 60 V |
| Dimming range | 1–100 % |
| PWM frequency | ≥1000 Hz |
| Mains surge capability (between L - N) | 1 kV |
| Mains surge capability (between L/N - PE) | 2 kV |
| Type of protection | IP20 |
| Length | 325 mm |
| Width | 43 mm |
| Height | 30 mm |
| Lifetime | up to 100000 h |
| Guarantee | 5 years |
| Output mode | CV |
| Maximum output power [W] | 200 |
| Nominal CV output voltage [V] | 24 |
| Input voltage | 220 – 240 V |
| IP grade | IP20 |
| Warranty [years] | 5 |
| THD | <5.4 % |
| Typ. efficiency at 230 V | 94 % |
| Dimensions L×W×H | 325 × 43 × 30 mm |
| Lifetime [h] | up to 100000 h |
| Product net weight | 0.431 kg |
| Interfaces and configuration | DALI, NFC, switchDIM |
| Dimming / control | DALI, switchDIM |
| Dimming | Yes |
| Configuration method | NFC |
| Manufacturer note: Product description | NEW: lumDATA (Luminaire data, Energy reporting and Diagnostics & Maintenance) |
| Manufacturer note: Product description | Dimmable 24 V constant voltage LED driver for flexible constant voltage strips |
| Manufacturer note: Product description | Can be either used built-in or independent with clip-on strain-relief (see data sheet chapter: 1. Standards) |
| Manufacturer note: Product description | The strain relief is included in both packaging variants. In the single packaging (SP) each Driver has also an individual packaging |
| Manufacturer note: Product description | one4all interface enables different dimming options |
| Manufacturer note: Product description | Dimming range 1 to 100 % |
| Manufacturer note: Product description | No additional external dimmer is needed |
| Manufacturer note: Product description | Suitable for emergency escape lighting systems acc. to EN 50172 |
| Manufacturer note: Product description | Nominal lifetime up to 50,000 h |
| Manufacturer note: Product description | 5 years guarantee (conditions at https://www.tridonic.com/en/int/services/manufacturer-guarantee-conditions) |
| Manufacturer note: Functions | LTI (Lifetime Indicator) |
| Manufacturer note: Typical applications | Cove lighting, facade accent lighting, ceiling integration |
| Manufacturer note: Technical details | 24 V, 200 W |
| Manufacturer note: Technical details | Small design (325 x 43 x 30 mm) with stretched-compact strain relief |
| Manufacturer note: Technical details | Small cross section |
| Manufacturer note: Technical details | Push terminals for simple wiring |
| Manufacturer note: Technical details | Output terminals (+/–) equipped twice for more flexibility in the application |
| Manufacturer note: Interfaces | Near field communication (NFC) |
| Manufacturer note: Interfaces | one4all (DALI-2, DSI, switchDIM, corridorFUNCTION) |
| Manufacturer note: Interfaces | Input terminal blocks: 45° push terminals |
| Manufacturer note: Interfaces | Output terminal blocks: 0° push terminals |
| Manufacturer note: System solution | Tridonic LLE-FLEX ADV 600, 1,200, 1,800 lm/m |
| Manufacturer note: System solution | Tridonic LLE-FLEX EXC 600, 1,200, 1,800, 2,500 lm/m |
| Manufacturer note: System solution | In connection with Flex accessories wire to PCB plug |
| Manufacturer note: System solution | Test the function of third party light sources before use at low dimming levels to ensure the dimming function works perfectly |
Operating points
| Point | Load | Output current | Output voltage | Typ. current consumption | Output power | Typ. power consumption | Ambient temperature ta | tc point max |
|---|---|---|---|---|---|---|---|---|
| 1 | 10.0 % | 834.0 mA | 24.0 V | 135 mA | 20 W; 20 W | 24.2 W | -25–70 °C | 85.0 °C |
| 2 | 20.0 % | 1668.0 mA | 24.0 V | 212 mA | 40 W; 40 W | 44.7 W | -25–70 °C | 85.0 °C |
| 3 | 30.0 % | 2502.0 mA | 24.0 V | 299 mA | 60 W; 60 W | 65.5 W | -25–70 °C | 85.0 °C |
| 4 | 40.0 % | 3336.0 mA | 24.0 V | 388 mA | 80 W; 80 W | 86.5 W | -25–70 °C | 85.0 °C |
| 5 | 50.0 % | 4170.0 mA | 24.0 V | 478 mA | 100 W; 100 W | 107.5 W | -25–70 °C | 88.0 °C |
| 6 | 60.0 % | 5004.0 mA | 24.0 V | 574 mA | 120 W; 120 W | 128.7 W | -25–60 °C | 89.0 °C |
| 7 | 70.0 % | 5838.0 mA | 24.0 V | 665 mA | 140 W; 140 W | 149.8 W | -25–60 °C | 89.0 °C |
| 8 | 80.0 % | 6672.0 mA | 24.0 V | 756 mA | 160 W; 160 W | 171 W | -25–60 °C | 89.0 °C |
| 9 | 90.0 % | 7506.0 mA | 24.0 V | 848 mA | 180 W; 180 W | 192.2 W | -25–55 °C | 89.0 °C |
| 10 | 100.0 % | 8340.0 mA | 24.0 V | 941 mA | 200 W; 200 W | 213.7 W | -25–45 °C | 86.0 °C |
Installation / application
Select the load for the documented voltage and permissible power. Dimming and installation details apply only to interfaces documented for this article.
Additional information
Warranty and declared lifetime are subject to manufacturer conditions. Other family versions do not establish the contents of this article; assess its exact model designation and assigned photographs together.
Main source of information: www.tridonic.com
We make every effort to ensure that the information presented in this product description is complete, up to date and consistent with source documentation. However, product ranges and specifications may evolve and be updated, and some changes may not yet be reflected in our description. Inaccuracies or errors may also occur in the source documentation itself. If you have any doubts or notice an error, please contact us at bok@ledownia.pl.
zas_tridonic_28004438
Data sheet
- Power supply type
- Constant Voltage (CV)
- Rated power [W]
- 200
- Output Voltage of CV power supply [V]
- 24
- Dimming / Control
- DALI, switchDIM
- Dimensions (L x W x H) [mm]
- 325 × 43 × 30 mm
- IP grade
- 20
- Length [mm]
- 325
- Width [mm]
- 43
- Height/thickness [mm]
- 30
- Warranty [years]
- 5
- Input voltage [V]
- 220-240
