LED power supply Tridonic DC 48V MULTI 30/50-1050/42 DA NF T
LED power supply Tridonic DC 48V MULTI 30W 50-1050mA 42V DA NF T is a LED power supply rated up to 30 W. Its adjustable output current range is 50–1050 mA. Documented interfaces and configuration methods: DALI, NFC.
LED power supply Tridonic DC 48V MULTI 30/50-1050/42 DA NF T
208.75 PLN
Shipment in 1-2 business days
zas_tridonic_28005582
LED power supply Tridonic DC 48V MULTI 30W 50-1050mA 42V DA NF T is a LED power supply rated up to 30 W. Its adjustable output current range is 50–1050 mA. Documented interfaces and configuration methods: DALI, NFC.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
LED power supply Tridonic DC 48V MULTI 30W 50-1050mA 42V DA NF T is a LED power supply in the DC 48V MULTI 30W 50–1050mA DA NF T family. Official article number 28005582 identifies this physical version.
Key properties
Common and exact-article specifications are kept separate from operating points. Power, LED voltage, efficiency and temperatures may depend on settings and load; the complete multi-row manufacturer data is shown below.
Technical specifications
| Manufacturer article number | 28005582 |
|---|---|
| Manufacturer family | DC 48V MULTI 30W 50–1050mA DA NF T |
| Manufacturer product group | Drivers without housing |
| DC voltage input | 48.0 V |
| DC voltage range | 46 – 51 V |
| Mains frequency | 0 Hz |
| Typ. current (at 230 V, 50 Hz, full load) | 673 mA |
| Power Consumption | 32.2 W |
| Output power range | 0.5–30 W |
| Typ. efficiency at 230 V | 94.3 % |
| Starting time | <0.7 s |
| Hold on time | <0.05 s |
| Output current tolerance, min./full load | ±10 %; ±5 % |
| Output LF current ripple | Same as LF ripple on 48 V bus |
| Max. output voltage | 60 V |
| Dimming range | 1–100 % |
| Max. casing temperature tc | 110 °C |
| ESD Classification | Severity level 2 |
| Type of protection | IP00 |
| Length | 116 mm |
| Width | 13 mm |
| Height | 6.2 mm |
| Guarantee | 5 years |
| Maximum output power [W] | 30 |
| Input voltage | 48.0 V |
| IP grade | IP00 |
| Warranty [years] | 5 |
| Maximum casing temperature tc | 110 °C |
| Typ. efficiency at 230 V | 94.3 % |
| Dimensions L×W×H | 116 × 13 × 6.2 mm |
| Minimum output current [mA] | 50 |
| Maximum output current [mA] | 1050 |
| Minimum operating output voltage [V] | 10 |
| Maximum operating output voltage [V] | 42 |
| Product net weight | 0.008 kg |
| Interfaces and configuration | DALI, NFC |
| Dimming / control | DALI |
| Dimming | Yes |
| Configuration method | NFC |
| short_circuit_protection | Yes |
| no_load_protection | Yes |
| Manufacturer note: Product description | DALI-2 dimmable |
| Manufacturer note: Product description | Up to 95.5 % efficiency |
| Manufacturer note: Product description | Output voltage range 10 – 42 V |
| Manufacturer note: Product description | Output current adjustable between 50 – 1050 mA |
| Manufacturer note: Product description | Pure AM dimming down to 1 % |
| Manufacturer note: Product description | Max. output power 30 W |
| Manufacturer note: Product description | Temperature range up to +35 °C |
| Manufacturer note: Product description | 5 years guarantee (conditions at https://www.tridonic.com/en/int/services/manufacturer-guarantee-conditions) |
| Manufacturer note: Housing properties | Pure PCB for built-in application |
| Manufacturer note: Housing properties | Compatible with STUCCHI 48V MULTI/EVO system, see data sheet chapter 6.15 |
| Manufacturer note: Housing properties | Suitable for class III applications |
| Manufacturer note: Interfaces | DALI – DT 6 |
| Manufacturer note: Interfaces | Terminal blocks: 0° push terminals |
| Manufacturer note: Interfaces | Near field communication (NFC) |
| Manufacturer note: Functions | Adjustable output current in 1-mA-steps (NFC, DALI-2) |
| Manufacturer note: Functions | lumDATA (DALI-2 part ext. 251, 252 and 253) |
| Manufacturer note: Functions | Protective features (overtemperature, short-circuit, no-load) |
| Manufacturer note: Functions | Protection against wrong wiring of 48V to DALI |
| Manufacturer note: Functions | Temperature declared thermally protected LED driver with integrated electronic protection means against overheating |
| Manufacturer note: Benefits | Application-oriented operating window |
| Manufacturer note: Benefits | Enabling even smaller dimensions for the miniaturization of luminaires |
| Manufacturer note: Benefits | Flexible configuration via companionSUITE (NFC, DALI-2) |
| Manufacturer note: Benefits | Support NFC multiple programming (1 carton with 10 pcs) |
| Manufacturer note: Typical applications | For downlight, spotlight and decorative applications |
Operating points
| Point | Output current | Min./Max. forward voltage | Typ. current consumption | Output power | Ambient temperature ta |
|---|---|---|---|---|---|
| 1 | 50.0 mA | 10 V; 42 V | 51.5 mA | 2.1 W; 2.1 W | 0–35 °C |
| 2 | 150.0 mA | 10 V; 42 V | 141 mA | 6.3 W; 6.3 W | 0–35 °C |
| 3 | 350.0 mA | 10 V; 42 V | 321.5 mA | 14.7 W; 14.7 W | 0–35 °C |
| 4 | 500.0 mA | 10 V; 42 V | 511.4 mA | 21 W; 21 W | 0–35 °C |
| 5 | 700.0 mA | 10 V; 42 V | 650.2 mA | 29.4 W; 29.4 W | 0–35 °C |
| 6 | 750.0 mA | 10 V; 40 V | 667.6 mA | 30 W; 30 W | 0–35 °C |
| 7 | 900.0 mA | 10 V; 33 V | 670.9 mA | 29.7 W; 29.7 W | 0–35 °C |
| 8 | 1050.0 mA | 10 V; 28 V | 672.6 mA | 29.4 W; 29.4 W | 0–35 °C |
Installation / application
Select the load for the documented voltage and permissible power. Dimming and installation details apply only to interfaces documented for this article.
Additional information
Warranty and declared lifetime are subject to manufacturer conditions. Other family versions do not establish the contents of this article; assess its exact model designation and assigned photographs together.
Main source of information: www.tridonic.com
We make every effort to ensure that the information presented in this product description is complete, up to date and consistent with source documentation. However, product ranges and specifications may evolve and be updated, and some changes may not yet be reflected in our description. Inaccuracies or errors may also occur in the source documentation itself. If you have any doubts or notice an error, please contact us at bok@ledownia.pl.
zas_tridonic_28005582
Data sheet
- Rated power [W]
- 30
- Dimming / Control
- DALI
- Dimensions (L x W x H) [mm]
- 116 × 13 × 6.2 mm
- IP grade
- IP00
- Length [mm]
- 116
- Width [mm]
- 13
- Height/thickness [mm]
- 6.2
- Warranty [years]
- 5
- Input voltage [V]
- 48.0 V
