LED power supply Tridonic LC 25/350-600/42 bDW NF T-W EXC3
LED power supply Tridonic LC 25W 350-600mA 42V bDW NF T-W EXC3 is a constant current LED driver rated up to 25 W. Its adjustable output current range is 350–600 mA. Documented interfaces and configuration methods: NFC, basicDIM Wireless, Casambi.
LED power supply Tridonic LC 25/350-600/42 bDW NF T-W EXC3
749.00 PLN
Shipment in 8-10 working days
zas_tridonic_28003055
LED power supply Tridonic LC 25W 350-600mA 42V bDW NF T-W EXC3 is a constant current LED driver rated up to 25 W. Its adjustable output current range is 350–600 mA. Documented interfaces and configuration methods: NFC, basicDIM Wireless, Casambi.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
LED power supply Tridonic LC 25W 350-600mA 42V bDW NF T-W EXC3 is a constant current LED driver in the Driver LC 25W 350-600mA 42V bDW NF T EXC3 family. Official article number 28003055 identifies this physical version.
Key properties
Common and exact-article specifications are kept separate from operating points. Power, LED voltage, efficiency and temperatures may depend on settings and load; the complete multi-row manufacturer data is shown below.
Technical specifications
| Manufacturer article number | 28003055 |
|---|---|
| Manufacturer family | Driver LC 25W 350-600mA 42V bDW NF T EXC3 |
| Manufacturer product group | in-track drivers |
| Supply voltage | 220 – 240 V |
| AC voltage range | 198 – 264 V |
| Mains frequency | 50 / 60 Hz |
| Overvoltage protection | 320 V AC, 48 h |
| Leakage current | <0.7 mA |
| Input current | 130 mA |
| Power Consumption | 29.6 W; 29.6 W |
| Typ. power input on stand-by 230 V | <0.5 W |
| Min. output power | 0.049 W |
| Typ. efficiency at 230 V | 83 % |
| λ over full operating range (max.) | 0.79–0.95C |
| THD at 230V, full load | <10 % |
| Starting time | <0.66 s |
| Turn off time | ≤0.03 s |
| Hold on time | 0 s |
| Output current tolerance, min./full load | ±5 % |
| Max. output peak current | ≤ output current +20 % |
| Output LF current ripple (< 120 Hz) / Current ripple at full load | ±3 % |
| Output P_ST_LM (at full load) | ≤1 |
| Output SVM (at full load) | ≤0.4 |
| Max. output voltage | 60 V |
| Dimming range | 1–100 % |
| Mains surge capability (between L - N) | 1 kV |
| Radio transceiver operation frequency | 2.4–2.483 GHz |
| Max. output power radio transceiver | < +20 dBm |
| Radio protocol | Bluetooth 4.0 or 5.0 Low Energy (BLE) |
| Capable for mesh-network | Up to 250 nodes / Standard networks and Long Range |
| Ambient temperature ta | 25 °C |
| Storage temperature ts | -40–80 °C |
| Type of protection | IP20 |
| Length | 231 mm |
| Width | 32 mm |
| Height | 43 mm |
| Lifetime | up to 100000 h |
| Guarantee | 5 years |
| Output mode | CC |
| Maximum output power [W] | 25 |
| Input voltage | 220 – 240 V |
| IP grade | IP20 |
| Warranty [years] | 5 |
| Storage temperature | -40–80 °C |
| THD | <10 % |
| Typ. efficiency at 230 V | 83 % |
| Dimensions L×W×H | 231 × 32 × 43 mm |
| Lifetime [h] | up to 100000 h |
| Minimum output current [mA] | 350 |
| Maximum output current [mA] | 600 |
| Product net weight | 0.15 kg |
| Interfaces and configuration | NFC, basicDIM Wireless, Casambi |
| Dimming / control | basicDIM Wireless, Casambi |
| Dimming | Yes |
| Configuration method | NFC |
| short_circuit_protection | Yes |
| overload_protection | Yes |
| no_load_protection | Yes |
| Manufacturer note: Product description | Can be integrated in Casambi systems (Casambi Ready) |
| Manufacturer note: Product description | Dimmable constant current / in-track LED driver |
| Manufacturer note: Product description | Optional accessory ACU ALU NIPPLE M10x1 for mounting the luminaire head |
| Manufacturer note: Product description | Compatible 3-phase system in-tracks, see data sheet chapter 3.8 |
| Manufacturer note: Product description | Forms automatically a wireless communication network with up to 250 nodes |
| Manufacturer note: Product description | Dimming range 1 to 100 % (min. 3.5 mA) |
| Manufacturer note: Product description | For luminaires of protection class II |
| Manufacturer note: Product description | Temperature protection as per EN 61347-2-13 C5e |
| Manufacturer note: Product description | Adjustable output current between 350 and 600 mA via near field communication (NFC) |
| Manufacturer note: Product description | Max. output power 25 W |
| Manufacturer note: Product description | Up to 85 % efficiency |
| Manufacturer note: Product description | Power input on stand-by < 0.5 W |
| Manufacturer note: Product description | Nominal lifetime up to 100,000 h |
| Manufacturer note: Product description | 5 years guarantee (conditions at https://www.tridonic.com/en/int/services/manufacturer-guarantee-conditions) |
| Manufacturer note: Product description | We will provide security updates for the next five years after the date of purchase of this product |
| Manufacturer note: Housing properties | Casing: polycarbonate, black, white or grey |
| Manufacturer note: Housing properties | Type of protection IP20 |
| Manufacturer note: Interfaces | basicDIM Wireless |
| Manufacturer note: Interfaces | Near field communication (NFC) |
| Manufacturer note: Functions | Adjustable output current in 1-mA-steps (NFC) |
| Manufacturer note: Functions | Overtemperature protection |
| Manufacturer note: Functions | Overload protection |
| Manufacturer note: Functions | Short-circuit protection |
| Manufacturer note: Functions | No-load protection |
| Manufacturer note: Functions | Burst protection voltage 2 kV |
| Manufacturer note: Functions | Surge protection voltage 1 kV (L to N) |
| Manufacturer note: Benefits | Flexible configuration via companionSUITE (NFC) |
| Manufacturer note: Benefits | Support NFC multiple programming (full carton box) |
| Manufacturer note: Typical applications | For spot light in retail and hospitality application |
Operating points
| Point | Output current | Min./Max. forward voltage | Typ. current consumption | Output power | Typ. power consumption | Ambient temperature ta | tc point max |
|---|---|---|---|---|---|---|---|
| 1 | 350.0 mA | 14 V; 42 V | 81 mA | 14.7 W | 18 W | -20–35 °C | 70.0 °C |
| 2 | 400.0 mA | 14 V; 42 V | 91 mA | 16.8 W | 20.3 W | -20–35 °C | 70.0 °C |
| 3 | 450.0 mA | 14 V; 42 V | 101 mA | 18.9 W | 22.6 W | -20–35 °C | 70.0 °C |
| 4 | 500.0 mA | 14 V; 42 V | 110 mA | 21 W | 24.9 W | -20–35 °C | 70.0 °C |
| 5 | 550.0 mA | 14 V; 42 V | 121 mA | 23.1 W | 27.3 W | -20–35 °C | 70.0 °C |
| 6 | 600.0 mA | 14 V; 41.7 V | 130 mA | 25 W | 29.7 W | -20–35 °C | 70.0 °C |
The Vmin/Vmax and CC operating-window filter features represent the global envelope of all documented settings. The complete operating-point table defines the permitted voltage at each current setting.
Installation / application
Select LED modules by comparing their forward voltage and current with the operating window at the chosen setting. Maximum tc and permissible ambient temperature apply under the conditions stated for each operating point.
Additional information
Warranty and declared lifetime are subject to manufacturer conditions. Other family versions do not establish the contents of this article; assess its exact model designation and assigned photographs together.
Main source of information: www.tridonic.com
We make every effort to ensure that the information presented in this product description is complete, up to date and consistent with source documentation. However, product ranges and specifications may evolve and be updated, and some changes may not yet be reflected in our description. Inaccuracies or errors may also occur in the source documentation itself. If you have any doubts or notice an error, please contact us at bok@ledownia.pl.
zas_tridonic_28003055
Data sheet
- Power supply type
- Constant Current (CC)
- Rated power [W]
- 25
- Output Current of CC power supply [mA]
- 350-600
- CC operating window
- 14-42
- Min. output voltage of led driver (CC)
- 14
- Max. output voltage of led driver (CC)
- 42
- Dimming / Control
- basicDIM Wireless, Casambi
- Dimensions (L x W x H) [mm]
- 231 × 32 × 43 mm
- IP grade
- 20
- Length [mm]
- 231
- Width [mm]
- 32
- Height/thickness [mm]
- 43
- Warranty [years]
- 5
- Input voltage [V]
- 220-240
- Min. current of CC driver [mA]
- 350
- Max. current of CC driver [mA]
- 600
