Mean Well SDR-240-24 240W 24V LED Power Supply
Mean Well SDR-240-24 is a 240 W, 24 V DC constant-voltage power supply for mounting on TS-35/7.5 or TS-35/15 DIN rail.
Mean Well SDR-240-24 240W 24V LED Power Supply
Minimum order quantity: 1. Order in multiples of 1.
422.76 PLN
Shipment in 1-2 business days
tm_SDR-240-24
Mean Well SDR-240-24 is a 240 W, 24 V DC constant-voltage power supply for mounting on TS-35/7.5 or TS-35/15 DIN rail.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
SDR-240-24 – full product specification
Mean Well SDR-240-24 is a SDR-240-series power supply rated at 240 W. The parameters below come from the exact official manufacturer datasheet.
Output and mounting
The supply operates in CV mode. Its output can be set across 0 V–0 V, and the enclosure mounts on TS-35/7.5 or TS-35/15 DIN rail.
Full technical specifications
| Dimensions | 63 × 125.2 × 113.5 mm |
|---|---|
| Document revision | SDR-240-SPEC 2025-02-17 |
| Typical efficiency | 894 % |
| Input range | 88–264 VAC / 124–370 VDC |
| Mounting | TS-35/7.5 or TS-35/15 DIN rail |
| Rated current | 10000 mA |
| Operating mode | Constant Voltage (CV) |
| Output voltage | 24 V |
| Over-voltage protection range | 29–33 V |
| Over-voltage protection | Yes |
| Rated power | 240 W |
| Weight | 1.03 kg |
| Withstand voltage | 3 kVAC |
Manufacturer datasheet
Complete source specification: official Mean Well datasheet.
tm_SDR-240-24
Data sheet
- Power supply type
- Constant Voltage (CV)
- Rated power [W]
- 100,1-249
- Output Voltage of CV power supply [V]
- 24
- Length [mm]
- 63
- Width [mm]
- 125.2
- Height/thickness [mm]
- 113.5
- Input voltage [V]
- 88-264
Specific References
- EAN13
- 4711287422381
- MPN
- SDR-240-24
