Mean Well DRA-60-12 60W 12V LED Power Supply

Name: Mean Well DRA-60-12 60W 12V LED Power Supply
Brand: Mean Well
SKU: tm_DRA-60-12
Price: 121.94 PLN
Availability: InStock

Minimum order quantity: 1. Order in multiples of 1.

121.94 PLN

Shipment in 1-2 business days

Reference: tm_DRA-60-12

Mean Well DRA-60-12 is a 60 W, 12 V DC constant-voltage power supply for mounting on TS-35/7.5 or TS-35/15 DIN rail.

Volume discounts

Quantity	Discounted price
5+	113.81 PLN
10+	105.68 PLN

Quantity

Delivery

1-3 dni (PL), 3-10 dni (non-PL)

Return Policy

14 days

DRA-60-12 – full product specification

Mean Well DRA-60-12 is a DRA-60-series power supply rated at 60 W. The parameters below come from the exact official manufacturer datasheet.

The supply operates in CV mode. Its output can be set across 0 V–0 V, and the enclosure mounts on TS-35/7.5 or TS-35/15 DIN rail.

Cooling	free-air convection
Dimensions	40 × 90 × 100 mm
Document revision	DRA-60-SPEC 2026-03-31
Typical efficiency	85 %
hold_up_time	230 vac ms: 50; 115 vac ms: 10
Input frequency	47–63 Hz
Input range	90–264 VAC / 127–370 VDC
Inrush current	30 A
Mounting	TS-35/7.5 or TS-35/15 DIN rail
Operating temperature	-30–70 °C
Rated current	5000 mA
Operating mode	Constant Voltage (CV)
CC-region maximum voltage	12 V
CC-region minimum voltage	3 V
Output voltage	12 V
Over-voltage protection range	14.49–18.63 V
Over-voltage protection	Yes
Short-circuit protection	Yes
Rated power	60 W
Manufacturer warranty	3 years
Weight	0.3 kg
Withstand voltage	3 kVAC
