Mean Well LPHC-18-350 16.8W 350mA 6–48V Constant Current (CC) LED driver
Mean Well LPHC-18-350 is a 16.8 W constant-current LED driver rated at 350 mA, with a 6–48 V DC output voltage range. IP rating IP67.
Mean Well LPHC-18-350 16.8W 350mA 6–48V Constant Current (CC) LED driver
Minimum order quantity: 1. Order in multiples of 1.
34.14 PLN
Shipment in 8-10 working days
tm_LPHC-18-350
Mean Well LPHC-18-350 is a 16.8 W constant-current LED driver rated at 350 mA, with a 6–48 V DC output voltage range. IP rating IP67.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
LPHC-18-350 – full product specification
Mean Well LPHC-18-350 is an LED power supply from the LPHC-18 series with a 16.8 W rated output. The verified manufacturer datasheet data below supports correct circuit and operating-condition selection.
Selection and output
Select this driver for an LED circuit rated at 350 mA. The required operating voltage of the complete powered circuit must remain within 6–48 V DC, while the connected load must also remain within the rated output power.
Input and efficiency
The specified input range is 180–264 VAC / 254–370 VDC. The input frequency range is 47–63 Hz. Manufacturer-specified typical efficiency is 80 %.
Full technical specifications
| Manufacturer | Mean Well |
|---|---|
| Series | LPHC-18 |
| Model | LPHC-18-350 |
| Operating mode | Constant Current (CC) |
| Rated power | 16.8 W |
| Output current | 350 mA |
| Output voltage range | 6–48 V DC |
| Input voltage range | 180–264 VAC / 254–370 VDC |
| Input frequency | 47–63 Hz |
| Typical efficiency | 80 % |
| Current accuracy | 8 % |
| Current ripple | 5 % |
| Inrush current | 50 A |
| Leakage current | 0.25 mA |
| Over-voltage protection range | 50.4–60 V |
| Short-circuit protection | Yes |
| Over-voltage protection | Yes |
| Cooling | free-air convection |
| Withstand voltage | 3 kVAC |
| Insulation resistance | 100 MΩ |
| IP rating | IP67 |
| Operating temperature | -30–70 °C |
| Dimensions (L × W × H) | 140 × 30 × 22 mm |
| Technical weight | 0.175 kg |
| Manufacturer warranty | 2 years |
Protection and construction
- Short-circuit protection: Yes
- Over-voltage protection: Yes
- Over-voltage protection range: 50.4–60 V
- Cooling: free-air convection
- Withstand voltage: 3 kVAC
- Insulation resistance: 100 MΩ
- IP rating: IP67
Operating conditions and mechanical data
Operating temperature: -30–70 °C; Dimensions (L × W × H): 140 × 30 × 22 mm; Technical weight: 0.175 kg; Manufacturer warranty: 2 years.
Manufacturer datasheet
The complete source specification is available directly from the manufacturer: Official Mean Well datasheet — LPHC-18-SPEC 2025-12-12.
Manufacturer information: Mean Well states that the LPHC-18 series is not intended for LED applications in the EU; for such applications, the manufacturer recommends the NPF, LPF or XLG series.
tm_LPHC-18-350
Data sheet
- Power supply type
- Constant Current (CC)
- Rated power [W]
- 15,1-20
- Output Current of CC power supply [mA]
- 350
- CC operating window
- 6-48
- Min. output voltage of led driver (CC)
- 6
- Max. output voltage of led driver (CC)
- 48
- Dimensions (L x W x H) [mm]
- 140/30/22
- IP grade
- 67
- Case type of power supply
- Waterproof
- Case type of power supply
- Isolated / secured
- Case material
- Plastic
- Length [mm]
- 140
- Grounding
- No
- Width [mm]
- 30
- Height/thickness [mm]
- 22
- Warranty [years]
- 2
- Input voltage [V]
- 180-264
- Interface
- Integrated input and output cable
Specific References
- MPN
- LPHC-18-350
