LED power supply | Tridonic LC 75/1100-1400/54 flexC lp SNC4

Name: LED power supply | Tridonic LC 75/1100-1400/54 flexC lp SNC4
Brand: Tridonic
SKU: zas_tridonic_28004144
Price: 97.55 PLN
Availability: InStock

97.55 PLN

Shipment in 1-2 business days

Category: Constant Current (CC)

Reference: zas_tridonic_28004144

Professional LED power supply Tridonic LC 75/1100-1400/54 flexC lp SNC4 with power up to 75.6 W. Adjustable output current 1100–1400 mA via DIP switch, efficiency up to 89% and lifetime up to 100,000 h. Perfect for linear, downlight and class I or II luminaires.

Delivery

1-3 dni (PL), 3-10 dni (non-PL)

Return Policy

14 days

Description
Product Details

LED power supply Tridonic LC 75/1100-1400/54 flexC lp SNC4 – technical data

Maximum power	75.6 W
Output power range	22 – 75.6 W
Output current range	1100 – 1400 mA (DIP switch)
Output current steps	1100, 1150, 1200, 1250, 1300, 1350, 1400 mA
Output voltage	20 – 54 V DC
Maximum U-OUT	60 V
Typical efficiency	up to 89%
THD at full load	< 15%
Power factor	up to 0.98
Supply voltage	220 – 240 V AC, 0 / 50 / 60 Hz
AC voltage range	198 – 264 V
DC voltage range	176 – 280 V
Max input current	0.37 A at 230 V
Protection class	SELV, for class I and II luminaires
Ingress protection	IP20
Ambient temperature ta	-20 ... +60 °C
Storage temperature	-40 ... +80 °C
Max tc temperature	85 / 90 °C (depending on current)
Lifetime	up to 100,000 h
Manufacturer warranty	5 years
Dimensions	280 x 30 x 21 mm
Fixing hole spacing	270 mm
Housing	ML300, white
Protections	overload, short circuit, no load
Emergency use	according to EN 50172 and EN 60598-2-22
Product website	http://www.tridonic.com/28004144

LED power supply for linear and downlight luminaires

This LED power supply Tridonic LC 75/1100-1400/54 flexC lp SNC4 is designed for built in use. It fits linear luminaires, downlights, panels and decorative fixtures. The slim ML300 housing with 280 mm length simplifies integration in narrow profiles.

The power supply offers constant current output with selectable levels from 1100 to 1400 mA. Setting is done via three position DIP switch after mains is disconnected. Maximum output power 75.6 W allows feeding longer LED boards and stronger panels.

LED power supply with high efficiency and long lifetime

Efficiency up to 89% reduces losses and heat inside the luminaire. Stable current regulation and low ripple help protect LED modules and light quality. Flicker metrics P_ST_LM ≤ 1 and SVM ≤ 0.4 support visual comfort in offices and retail.

The nominal lifetime reaches up to 100,000 hours under specified conditions. A 5 year manufacturer warranty confirms the robustness of this solution. Integrated protections against overload, short circuit and no load increase safety.

LED power supply compliant with standards and emergency systems

The unit meets many standards, including EN 61347-1, EN 61347-2-13 and EN 62384. It also fulfils EMC requirements EN 55015 and EN 61547 for stable operation. The power supply is suitable for central battery systems according to EN 50172.

It can be used in emergency lighting luminaires according to EN 60598-2-22. In DC operation the light output level stays around 95% of nominal AC mode. This is important for escape routes and safety related installations.

LED power supply easy to install and wire

The product uses push wire terminals for fast and reliable wiring on site. Allowed conductor cross section is 0.5 – 1.5 mm² with stripping length 8.5 – 9.5 mm. Maximum total length of LED output wiring is 2 m for best EMC behavior.

The housing provides fixing points for screws with torque up to 0.5 Nm. Earthing of the ML300 case is recommended, especially with grounded heat sinks. Following the wiring guidelines ensures reliable and long term operation of the power supply.
