Mean Well HLN-40H-12A 40 W CV+CC LED driver
Mean Well HLN-40H-12A is a 40 W CV+CC LED driver with a 7.2 V–12 V constant-current region.
Mean Well HLN-40H-12A 40 W CV+CC LED driver
Minimum order quantity: 1. Order in multiples of 1.
146.33 PLN
Shipment in 1-2 business days
tm_HLN-40H-12A
Mean Well HLN-40H-12A is a 40 W CV+CC LED driver with a 7.2 V–12 V constant-current region.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
HLN-40H-12A – full product specification
Mean Well HLN-40H-12A is a HLN-40H-series power supply rated at 40 W. The parameters below come from the exact official manufacturer datasheet.
CV+CC operation
The driver combines voltage regulation and current limiting; its constant-current region is 7.2 V–12 V DC.
Full technical specifications
| Fully isolated enclosure | Yes |
|---|---|
| Enclosure material | plastic |
| 3-in-1 dimming | Yes |
| Cooling | free-air convection |
| Dimensions | 161 × 61.5 × 35 mm |
| Document revision | HLN-40H-SPEC 2026-02-09 |
| Typical efficiency | 86.5 % |
| hold_up_time | 230 vac ms: 16; 115 vac ms: 16 |
| Input frequency | 47–63 Hz |
| Input range | 90–305 VAC / 127–431 VDC |
| Inrush current | 50 A |
| IP rating | IP64 |
| Operating temperature | -40–50 °C |
| Rated current | 3330 mA |
| Operating mode | Constant voltage + constant current (CV+CC) |
| CC-region maximum voltage | 12 V |
| CC-region minimum voltage | 7.2 V |
| Output voltage | 12 V |
| Over-voltage protection | Yes |
| Short-circuit protection | Yes |
| Rated power | 40 W |
| Manufacturer warranty | 3 years |
| Weight | 0.35 kg |
Manufacturer datasheet
Complete source specification: official Mean Well datasheet.
Manufacturer information: Mean Well states that the HLN-40H series is not intended for LED applications in the EU and China; the manufacturer recommends the LPF, NPF, XLG, XLC or XLN series.
tm_HLN-40H-12A
Data sheet
- Power supply type
- CV+CC
- Rated power [W]
- 30,1-60
- Output Current of CC power supply [mA]
- 3330
- CC operating window
- 7.2-12
- Min. output voltage of led driver (CC)
- 7.2
- Max. output voltage of led driver (CC)
- 12
- IP grade
- 64
- Length [mm]
- 161
- Width [mm]
- 61.5
- Height/thickness [mm]
- 35
- Warranty [years]
- 3
- Input voltage [V]
- 90-305
Specific References
- EAN13
- 4711287460789
- MPN
- HLN-40H-12A
