Mean Well ELG-300-24A 300 W CV+CC LED driver
Mean Well ELG-300-24A is a 300 W CV+CC LED driver with a 14.4 V–24 V constant-current region.
Mean Well ELG-300-24A 300 W CV+CC LED driver
Minimum order quantity: 1. Order in multiples of 1.
357.72 PLN
Shipment in 1-2 business days
tm_ELG-300-24A
Mean Well ELG-300-24A is a 300 W CV+CC LED driver with a 14.4 V–24 V constant-current region.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
ELG-300-24A – full product specification
Mean Well ELG-300-24A is a ELG-300-series power supply rated at 300 W. The parameters below come from the exact official manufacturer datasheet.
CV+CC operation
The driver combines voltage regulation and current limiting; its constant-current region is 14.4 V–24 V DC.
Full technical specifications
| Dimensions | 246 × 77 × 39.5 mm |
|---|---|
| Document revision | ELG-300-SPEC 2026-02-04 |
| Typical efficiency | 94 % |
| Input frequency | 47–63 Hz |
| Input range | 100–305 VAC / 142–431 VDC |
| Inrush current | 45 A |
| IP rating | IP67 |
| Rated current | 12500 mA |
| Operating mode | Constant voltage + constant current (CV+CC) |
| CC-region maximum voltage | 24 V |
| CC-region minimum voltage | 14.4 V |
| Output voltage | 24 V |
| Over-voltage protection range | 27–34 V |
| Over-voltage protection | Yes |
| Short-circuit protection | Yes |
| Rated power | 300 W |
| Manufacturer warranty | 5 years |
Manufacturer datasheet
Complete source specification: official Mean Well datasheet.
tm_ELG-300-24A
Data sheet
- Power supply type
- CV+CC
- Rated power [W]
- 250-499
- Output Current of CC power supply [mA]
- 12500
- CC operating window
- 14.4-24
- Min. output voltage of led driver (CC)
- 14.4
- Max. output voltage of led driver (CC)
- 24
- IP grade
- 67
- Length [mm]
- 246
- Width [mm]
- 77
- Height/thickness [mm]
- 39.5
- Warranty [years]
- 5
- Input voltage [V]
- 100-305
Specific References
- EAN13
- 4711287443379
- MPN
- ELG-300-24A
