LED strip SMD 3528 12V 19.2W/m warm white 240LED/m IP33 5m

LED Strip - Construction

The strip uses SMD technology with LEDs in a 3528 package. The underside has factory-applied double-sided adhesive tape to aid installation on a suitably prepared surface.

Control of LED strip

The strip can be powered directly from a suitable 12V power supply. An optional PWM controller enables brightness adjustment.

Important information

The stated power is a rated or theoretical value based on the parameters of the components used. Actual power consumption may be lower due to component tolerances, voltage drop and operating conditions.

Power and installation

The strip does not require an additional power-injection point when its length does not exceed 5m. Above this length, consider starting the next separately powered run, supplying the run at its far end, or adding another power point after the indicated length.

The 5m value is based on the electrical properties of the strip PCB. It indicates the length at which supply-voltage drop should not cause a noticeable reduction in LED brightness along the length of strip. Above this length, a brightness difference may become visible. If it remains acceptable to the end customer, the final power-feed arrangement is the responsibility of the installation designer or user.

Light emitted by LED strip

The presented white LED strip is a single-channel light source with a color temperature of 3000K. All LEDs emit the same color and are controlled simultaneously, providing uniform and stable illumination.

In most white LEDs, light is produced through a phosphor-conversion process. A blue semiconductor chip emits short-wavelength radiation, part of which is converted by a phosphor layer into longer-wavelength visible light. The combination of the original blue light and the radiation emitted by the phosphor creates a broad spectrum perceived by the human eye as white light.

The composition and proportions of the phosphor materials make it possible to control the color temperature, tint, luminous efficacy, and color rendering quality with high precision. In high-quality LEDs, a properly engineered spectrum can faithfully reproduce the natural appearance of illuminated objects and colors, bringing the character of the emitted light close to daylight or traditional incandescent lighting. Particularly important factors include a high color rendering index, the correct balance of spectral components, and strict LED binning for color consistency. As a result, in typical applications, the light produced by a high-quality LED strip can be visually very difficult to distinguish from that of natural or traditional light sources.

During operation, an LED ages gradually rather than failing suddenly through a conventional “burnout.” The most commonly observed process is a slow reduction in luminous flux over time. High operating temperatures can accelerate degradation of the semiconductor structure, phosphor, package materials, and electrical connections. Over time, the phosphor may lose some of its conversion efficiency, while optical materials may become discolored, leading to a slight shift in color temperature or chromaticity coordinates.

In high-quality LED strips, this aging process is slow, uniform, and predictable. Proper thermal management, stable power supply, and installation in a suitable aluminum profile reduce the operating temperature, helping to preserve the original brightness and light color for many years.

For static operation, the strip does not require a controller — a correctly selected power supply is sufficient. Brightness adjustment requires a compatible single-channel LED dimmer or controller, most commonly using PWM modulation.

LED strip - product overview

The strip operates at 12V and has a density of 240LED/m with an IP33 ingress-protection rating.

Sales unit of led strip

The sales unit includes a factory-prepared reel of LED strip with a length of 5m.

LED strip - power supply selection

The strip requires a power supply with an output voltage of 12V. Guidance: select a power supply with an optimum 30% power reserve above the LED strip demand.

Premium warm white LED strip 1200LED SMD 3528 is built for projects where you want a clean, continuous light line. The very high diode density reduces visible dots and delivers a smooth glow in aluminum profiles. SMD 3528 LEDs keep the color stable and pleasant. Warm white adds a cozy mood in living rooms, bedrooms, and hospitality interiors.

Why choose a premium warm white LED strip 1200LED SMD 3528?

This strip uses selected components and consistent binning. You get reliable output, steady tone, and a professional finish. It is a great choice for accent lighting, indirect ceiling lines, and furniture illumination.

Best use cases

• Cabinets, shelves, niches, and display cases
• Architectural accents, coves, and soffits
• Signage, showcases, and retail displays
• Aluminum profiles for smooth linear lighting

Power supply and voltage drop

Choose a constant-voltage power supply matched to the strip load. Add a 20–30% power reserve for long life and stable work. Look for protection features like OVP, OCP, SCP, and OTP. Models with active PFC can improve overall performance.

For longer runs, voltage drop can reduce brightness. Use power injection to keep the line even. For 12V systems, feed power about every 5 m. For 24V systems, feed power about every 10 m. Use a star wiring layout and proper wire gauge. Protect connections from moisture in outdoor or humid areas.

Installation and cutting

Install the strip on a clean surface. You can cut it only at marked cutting points. Connect sections with soldering or quality connectors. An aluminum profile improves cooling and helps maintain brightness over time. This premium warm white LED strip 1200LED SMD 3528 works especially well in profiles.

FAQ

• Which power supply should I choose? Add up the total wattage and include 20–30% headroom. Pick a unit with OVP/OCP/SCP/OTP.
• When do I need power injection? Use it on long runs or high-density strips. It keeps brightness consistent along the length.
• Can I cut and reconnect the strip? Yes, at the cut marks. Soldering gives the most reliable connection.
