LED power supply Tridonic LCO 24V DC 40/200-1050/77 pD+ NF C PRE3
LED power supply Tridonic LCO 24V DC 40W 200-1050mA 77V pD+ NF C PRE3 is a constant current LED driver rated up to 40 W. Its adjustable output current range is 200–1050 mA. Documented interfaces and configuration methods: DALI, NFC.
LED power supply Tridonic LCO 24V DC 40/200-1050/77 pD+ NF C PRE3
541.00 PLN
Shipment in 8-10 working days
zas_tridonic_87501217
LED power supply Tridonic LCO 24V DC 40W 200-1050mA 77V pD+ NF C PRE3 is a constant current LED driver rated up to 40 W. Its adjustable output current range is 200–1050 mA. Documented interfaces and configuration methods: DALI, NFC.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
LED power supply Tridonic LCO 24V DC 40W 200-1050mA 77V pD+ NF C PRE3 is a constant current LED driver in the Driver LCO 24V DC 40W 200–1050mA 77V pD+ NF C PRE3 family. Official article number 87501217 identifies this physical version.
Key properties
Common and exact-article specifications are kept separate from operating points. Power, LED voltage, efficiency and temperatures may depend on settings and load; the complete multi-row manufacturer data is shown below.
Technical specifications
| Manufacturer article number | 87501217 |
|---|---|
| Manufacturer family | Driver LCO 24V DC 40W 200–1050mA 77V pD+ NF C PRE3 |
| Manufacturer product group | Compact drivers |
| DC voltage range | 23.2 – 30 V |
| Typ. current (at 25.6 V, 0 Hz, full load) | 1750.0 mA |
| Typ. power consumption (at 25.6 V, 0 Hz, full load) | 44.7 W |
| Output power range | 3.6–40 W |
| Typ. efficiency (at 25.6 V, 0 Hz, full load) | 91.0 % |
| Starting time | 0.5 s; 0.85 s |
| Turn off time | 0.03 s |
| Output current tolerance, min./full load | ±3 % |
| Max. output current peak (non-repetitive) + max. peak output current | ≤ output current +15 % |
| Output LF current ripple (< 120 Hz) / Current ripple at full load | ±3.3 % |
| Max. output voltage | 90 V |
| Dimming range | 1–100 % |
| Type of protection | IP67 |
| Length | 162.5 mm |
| Width | 73 mm |
| Height | 43 mm |
| Lifetime | up to 50000 h |
| Guarantee | 8 years |
| Output mode | CC |
| Maximum output power [W] | 40 |
| IP grade | IP67 |
| Warranty [years] | 8 |
| Dimensions L×W×H | 162.5 × 73 × 43 mm |
| Lifetime [h] | up to 50000 h |
| Minimum output current [mA] | 200 |
| Maximum output current [mA] | 1050 |
| Product net weight | 0.723 kg |
| Interfaces and configuration | DALI, NFC |
| Dimming / control | DALI |
| Dimming | Yes |
| Configuration method | NFC |
| short_circuit_protection | Yes |
| overload_protection | Yes |
| no_load_protection | Yes |
| Manufacturer note: Product description | DC Driver for 24V input applications |
| Manufacturer note: Product description | Uses standard zhaga interfaces for sensor connection allowing further battery/ energy savings |
| Manufacturer note: Product description | Suitable for DALI-2 sensors and communication nodes |
| Manufacturer note: Product description | Dimmable independent constant current LED driver |
| Manufacturer note: Product description | Max. output power 40 W |
| Manufacturer note: Product description | Adjustable output current between 200 and 1050 mA |
| Manufacturer note: Product description | Power input on stand-by < 0.35 W |
| Manufacturer note: Product description | Up to 91.5 % efficiency |
| Manufacturer note: Product description | Dimming range 1 to 100 % (min. 10 mA) |
| Manufacturer note: Product description | For luminaires of protection class III |
| Manufacturer note: Product description | 8 years guarantee (conditions at https://www.tridonic.com/en/int/services/manufacturer-guarantee-conditions) |
| Manufacturer note: Interfaces | Near field communication (NFC) |
| Manufacturer note: Interfaces | Powered DALI-2 |
| Manufacturer note: Interfaces | Interface for zhaga book 18 compliant socket |
| Manufacturer note: Functions | Adjustable output current in 1-mA-steps (NFC, DALI) |
| Manufacturer note: Functions | Enhanced constant light output function (eCLO) |
| Manufacturer note: Functions | Protective features (overtemperature, short-circuit, overload, no-load, input voltage range) |
| Manufacturer note: Functions | Fulfills DALI-2 parts: 105 (DALI firmware update), 150 (Auxiliary power supply), 250 (Integrated bus power supply), 251 (Luminaire data), 252 (Energy reporting) and 253 (Diagnostics & Maintenance) |
| Manufacturer note: Functions | Intelligent Temperature Guard (ITG) |
| Manufacturer note: Functions | 24 V, 3 W power supply |
| Manufacturer note: Functions | DiiA/Zhaga connectivity extensions DT49, DT50, DT51, DT52 |
| Manufacturer note: Functions | deviceKEY against unauthorized change of parameters |
| Manufacturer note: Benefits | Flexible configuration via companionSUITE (NFC, DALI) |
| Manufacturer note: Benefits | Low standby losses for further autonomy |
| Manufacturer note: Benefits | Protection against battery deep discharge |
| Manufacturer note: Benefits | In-field programming possible after installation with NFC interface |
| Manufacturer note: Benefits | Suitable for supplies with 24V systems |
| Manufacturer note: Benefits | Designed for usage in combination with MPPT charge controllers for independent SOLAR street light applications |
| Manufacturer note: Typical applications | Solar street lights |
| Manufacturer note: Typical applications | Low voltage DC applications |
| Manufacturer note: Typical applications | Off grid applications |
| Manufacturer note: Typical applications | Other 24V battery applications (boats, camping, traffic signs…) |
Operating points
| Point | Output current | Min./Max. forward voltage | Typ. current consumption | Output power | Typ. power consumption | Ambient temperature ta | tc point max |
|---|---|---|---|---|---|---|---|
| 1 | 200.0 mA | 18 V; 77 V | 672 mA | 15.4 W | 17.2 W | -40–70 °C | 74.0 °C |
| 2 | 250.0 mA | 18 V; 77 V | 831 mA | 19.3 W | 21.2 W | -40–70 °C | 74.0 °C |
| 3 | 300.0 mA | 18 V; 77 V | 990 mA | 23.1 W | 25.3 W | -40–70 °C | 74.0 °C |
| 4 | 350.0 mA | 18 V; 77 V | 1149 mA | 27 W | 29.4 W | -40–70 °C | 74.0 °C |
| 5 | 400.0 mA | 18 V; 77 V | 1310 mA | 30.8 W | 33.5 W | -40–70 °C | 74.0 °C |
| 6 | 450.0 mA | 18 V; 77 V | 1472 mA | 34.7 W | 37.7 W | -40–65 °C | 74.0 °C |
| 7 | 500.0 mA | 18 V; 77 V | 1633 mA | 38.5 W | 41.8 W | -40–65 °C | 74.0 °C |
| 8 | 520.0 mA | 18 V; 77 V | 1699 mA | 40 W | 43.5 W | -40–65 °C | 74.0 °C |
| 9 | 600.0 mA | 18 V; 66.7 V | 1703 mA | 40 W | 43.6 W | -40–65 °C | 74.0 °C |
| 10 | 650.0 mA | 18 V; 61.5 V | 1709 mA | 40 W | 43.7 W | -40–65 °C | 74.0 °C |
| 11 | 700.0 mA | 18 V; 57.1 V | 1712 mA | 40 W | 43.8 W | -40–65 °C | 74.0 °C |
| 12 | 750.0 mA | 18 V; 53.3 V | 1716 mA | 40 W | 43.9 W | -40–65 °C | 74.0 °C |
| 13 | 800.0 mA | 18 V; 50 V | 1721 mA | 40 W | 44 W | -40–65 °C | 74.0 °C |
| 14 | 850.0 mA | 18 V; 47.1 V | 1726 mA | 40 W | 44.1 W | -40–60 °C | 74.0 °C |
| 15 | 900.0 mA | 18 V; 44.4 V | 1730 mA | 40 W | 44.2 W | -40–60 °C | 74.0 °C |
| 16 | 950.0 mA | 18 V; 42.1 V | 1736 mA | 40 W | 44.4 W | -40–60 °C | 74.0 °C |
| 17 | 1000.0 mA | 18 V; 40 V | 1741 mA | 40 W | 44.5 W | -40–60 °C | 74.0 °C |
| 18 | 1050.0 mA | 18 V; 38.1 V | 1747 mA | 40 W | 44.7 W | -40–60 °C | 74.0 °C |
The Vmin/Vmax and CC operating-window filter features represent the global envelope of all documented settings. The complete operating-point table defines the permitted voltage at each current setting.
Installation / application
Select LED modules by comparing their forward voltage and current with the operating window at the chosen setting. Maximum tc and permissible ambient temperature apply under the conditions stated for each operating point.
Additional information
Warranty and declared lifetime are subject to manufacturer conditions. Other family versions do not establish the contents of this article; assess its exact model designation and assigned photographs together.
Main source of information: www.tridonic.com
We make every effort to ensure that the information presented in this product description is complete, up to date and consistent with source documentation. However, product ranges and specifications may evolve and be updated, and some changes may not yet be reflected in our description. Inaccuracies or errors may also occur in the source documentation itself. If you have any doubts or notice an error, please contact us at bok@ledownia.pl.
zas_tridonic_87501217
Data sheet
- Power supply type
- Constant Current (CC)
- Rated power [W]
- 40
- Output Current of CC power supply [mA]
- 200-1050
- CC operating window
- 18-77
- Min. output voltage of led driver (CC)
- 18
- Max. output voltage of led driver (CC)
- 77
- Dimming / Control
- DALI
- Dimensions (L x W x H) [mm]
- 162.5 × 73 × 43 mm
- IP grade
- 67
- Length [mm]
- 162.5
- Width [mm]
- 73
- Height/thickness [mm]
- 43
- Warranty [years]
- 8
- Min. current of CC driver [mA]
- 200
- Max. current of CC driver [mA]
- 1050
