LED power supply Tridonic LCBI 15W 700mA BASIC PHASE-CUT LP
LED power supply Tridonic LCBI 15W 700mA BASIC PHASE-CUT LP is a LED power supply. Values for individual settings are shown in the operating-point table.Load selection depends on the applicable operating window.
LED power supply Tridonic LCBI 15W 700mA BASIC PHASE-CUT LP
133.75 PLN
Shipment in 1-2 business days
zas_tridonic_89800257
LED power supply Tridonic LCBI 15W 700mA BASIC PHASE-CUT LP is a LED power supply. Values for individual settings are shown in the operating-point table.Load selection depends on the applicable operating window.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
LED power supply Tridonic LCBI 15W 700mA BASIC PHASE-CUT LP is a LED power supply in the Driver LCBI 15W 350/500/700mA BASIC phase-cut lp family. Official article number 89800257 identifies this physical version.
Key properties
Common and exact-article specifications are kept separate from operating points. Power, LED voltage, efficiency and temperatures may depend on settings and load; the complete multi-row manufacturer data is shown below.
Technical specifications
| Manufacturer article number | 89800257 |
|---|---|
| Manufacturer family | Driver LCBI 15W 350/500/700mA BASIC phase-cut lp |
| Manufacturer product group | Compact drivers |
| Supply voltage | 220 – 240 V |
| AC voltage range | 198 – 264 V |
| Mains frequency | 50 / 60 Hz |
| Starting time | ≤0.1 s |
| Turn off time | ≤0.1 s |
| Hold on time | 0 s |
| Max. non-repetitive output peak current | 1640 mA; 1280 mA |
| Output LF current ripple (< 120 Hz) / Current ripple at full load | ±30 % |
| Storage temperature ts | -40–85 °C |
| Guarantee | 5 years |
| Output current | 700 mA |
| Typ. current (at 230 V, 50 Hz, full load) | 100 mA |
| Min./Max. forward voltage | 10 V; 21.5 V |
| Output voltage range (DC) | 10–21.5 V |
| Max. output voltage | 24 V |
| Typ. output power | 15 W |
| Power Consumption | 20 W |
| Efficiency at min./full load | 74 %; 76 % |
| λ over full operating range (max.) | 0.99 |
| λ over full operating range (min.) | 0.97 |
| Output current tolerance, min./full load | ±7.5 % |
| Max. (repetitive) output peak current (at min./full load) | 1640 mA; 1280 mA |
| Output current ripple | ±30 % |
| Ambient temperature ta | -25–50 °C |
| Max. casing temperature tc | 85 °C |
| Lifetime | up to 50000 h |
| Length | 139 mm |
| Width | 30 mm |
| Height | 21 mm |
| Input voltage | 220 – 240 V |
| Warranty [years] | 5 |
| Maximum casing temperature tc | 85 °C |
| Storage temperature | -40–85 °C |
| λ over full operating range (max.) | 0.99 |
| Dimensions L×W×H | 139 × 30 × 21 mm |
| Lifetime [h] | up to 50000 h |
| Product net weight | 0.053 kg |
| Dimming | Yes |
| SELV | Yes |
| short_circuit_protection | Yes |
| overload_protection | Yes |
| no_load_protection | Yes |
| Manufacturer note: Product description | Dimmable via leading edge and trailing edge phase dimmers |
| Manufacturer note: Product description | Output dimmed analogue (current amplitude) |
| Manufacturer note: Product description | Dimming range typ. 5 to 100 % (depending on dimmer) |
| Manufacturer note: Product description | Type of protection IP20 |
| Manufacturer note: Product description | Push-in terminals |
| Manufacturer note: Product description | Connecting cable, wire cross-section 0.5 – 1.5 mm² |
| Manufacturer note: Product description | SELV |
| Manufacturer note: Product description | Output current 700 mA |
| Manufacturer note: Product description | Output power 15/16 W |
| Manufacturer note: Product description | Nominal lifetime of 50,000 h (at max ta 50 °C with a failure rate ≤ 0.2 % per 1,000 h) |
| Manufacturer note: Product description | 5 years guarantee (conditions at https://www.tridonic.com/en/int/services/manufacturer-guarantee-conditions) |
| Manufacturer note: Properties | Casing: polycarbonate, white |
| Manufacturer note: Properties | Compact dimensions |
| Manufacturer note: Properties | Overload protection |
| Manufacturer note: Properties | Short-circuit protection |
| Manufacturer note: Properties | No-load protection |
Operating points
| Point | Output current | Typ. current (at 230 V, 50 Hz, full load) | Min./Max. forward voltage | Output voltage range (DC) | Max. output voltage | Typ. output power | Power Consumption | Efficiency at min./full load | λ over full operating range (max.) | λ over full operating range (min.) | Output current tolerance, min./full load | Max. (repetitive) output peak current (at min./full load) | Max. non-repetitive output peak current | Output current ripple | Ambient temperature ta | Max. casing temperature tc | Lifetime | Length | Width | Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | 700 mA | 100 mA | 10 V; 21.5 V | 10–21.5 V | 24 V | 15 W | 20 W | 74 %; 76 % | 0.99 | 0.97 | ±7.5 % | 1640 mA; 1280 mA | 1640 mA; 1280 mA | ±30 % | -25–50 °C | 85 °C | up to 50000 h | 139 mm | 30 mm | 21 mm |
Installation / application
Select the load for the documented voltage and permissible power. Dimming and installation details apply only to interfaces documented for this article.
Additional information
Warranty and declared lifetime are subject to manufacturer conditions. Other family versions do not establish the contents of this article; assess its exact model designation and assigned photographs together.
Main source of information: www.tridonic.com
We make every effort to ensure that the information presented in this product description is complete, up to date and consistent with source documentation. However, product ranges and specifications may evolve and be updated, and some changes may not yet be reflected in our description. Inaccuracies or errors may also occur in the source documentation itself. If you have any doubts or notice an error, please contact us at bok@ledownia.pl.
zas_tridonic_89800257
Data sheet
- Dimensions (L x W x H) [mm]
- 139 × 30 × 21 mm
- Length [mm]
- 139
- Width [mm]
- 30
- Height/thickness [mm]
- 21
- Warranty [years]
- 5
- Input voltage [V]
- 220-240
- Power factor
- 0.99
