Mean Well IDPV-45-48 45.12 W PWM-output CV LED driver 48 V DC
Mean Well IDPV-45-48 45.12 W PWM-output CV LED driver 48 V DC – dimensions
Mean Well IDPV-45-48 45.12 W PWM-output CV LED driver 48 V DC – dimming diagram
Mean Well IDPV-45-48 45.12 W PWM-output CV LED driver 48 V DC – block diagram
Mean Well IDPV-45-48 45.12 W PWM-output CV LED driver 48 V DC – efficiency versus load characteristic
Mean Well IDPV-45-48 45.12 W PWM-output CV LED driver 48 V DC – load versus temperature characteristic

Mean Well IDPV-45-48 45.12W 48V LED Power Supply

Minimum order quantity: 1. Order in multiples of 1.
39.02 PLN
Shipment in 1-2 business days
Constant Voltage (CV)
tm_IDPV-45-48

Mean Well IDPV-45-48 is a 45.12 W, 48 V DC constant-voltage LED driver with PWM-modulated output.

Volume discounts

Quantity Discounted price
5+ 37.39 PLN
10+ 36.58 PLN
20+ 34.14 PLN
Quantity
Wishlist
Compare
  Delivery

1-3 dni (PL), 3-10 dni (non-PL)



Privacy Policy

  Return Policy

14 days

IDPV-45-48 – full product specification

Mean Well IDPV-45-48 is a IDPV-45-series power supply rated at 45.12 W. The parameters below come from the exact official manufacturer datasheet.

CV PWM output

The model supplies 48 V DC while brightness is represented by output PWM modulation.

Full technical specifications

Dimensions120 × 66.5 × 22 mm
Document revisionIDPV-45-SPEC 2022-02-18
Typical efficiency88 %
Input frequency47–63 Hz
Input range90–295 VAC / 127–417 VDC
Inrush current30 A
Output modulationPWM
Rated current940 mA
Operating modeConstant Voltage (CV)
Output voltage48 V
Short-circuit protectionYes
Rated power45.12 W
Manufacturer warranty3 years
Weight0.14 kg

Manufacturer datasheet

Complete source specification: official Mean Well datasheet.

tm_IDPV-45-48

Data sheet

Power supply type
Constant Voltage (CV)
Rated power [W]
30,1-60
Output Voltage of CV power supply [V]
48
Length [mm]
120
Width [mm]
66.5
Height/thickness [mm]
22
Warranty [years]
3
Input voltage [V]
90-295

Specific References

EAN13
4711287462509
MPN
IDPV-45-48
