Mean Well DDR-30G-5 30W 5V LED Power Supply
Mean Well DDR-30G-5 is a 30 W, 5 V DC constant-voltage power supply for mounting on TS-35/7.5 or TS-35/15 DIN rail.
Mean Well DDR-30G-5 30W 5V LED Power Supply
Minimum order quantity: 1. Order in multiples of 1.
138.20 PLN
Shipment in 1-2 business days
tm_DDR-30G-5
Mean Well DDR-30G-5 is a 30 W, 5 V DC constant-voltage power supply for mounting on TS-35/7.5 or TS-35/15 DIN rail.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
DDR-30G-5 – full product specification
Mean Well DDR-30G-5 is a DDR-30-series power supply rated at 30 W. The parameters below come from the exact official manufacturer datasheet.
Output and mounting
The supply operates in CV mode. Its output can be set across 0 V–0 V, and the enclosure mounts on TS-35/7.5 or TS-35/15 DIN rail.
Full technical specifications
| Cooling | free-air convection |
|---|---|
| Dimensions | 35 × 90 × 54.5 mm |
| Document revision | DDR-30-SPEC 2026-03-31 |
| Typical efficiency | 85 % |
| Mounting | TS-35/7.5 or TS-35/15 DIN rail |
| Operating temperature | -40–85 °C |
| Rated current | 6000 mA |
| Operating mode | Constant Voltage (CV) |
| Output voltage | 5 V |
| Over-voltage protection range | 5.75–7 V |
| Over-voltage protection | Yes |
| Short-circuit protection | Yes |
| Rated power | 30 W |
| Manufacturer warranty | 3 years |
| Weight | 0.12 kg |
Manufacturer datasheet
Complete source specification: official Mean Well datasheet.
tm_DDR-30G-5
Data sheet
- Power supply type
- Constant Voltage (CV)
- Rated power [W]
- 20,1-30
- Output Voltage of CV power supply [V]
- 5
- Length [mm]
- 35
- Width [mm]
- 90
- Height/thickness [mm]
- 54.5
- Warranty [years]
- 3
Specific References
- EAN13
- 4711287422831
- MPN
- DDR-30G-5
