Mean Well APV-12-24 12 W 24 V DC CV LED power supply

Mean Well APV-12-24 12 W 24 V DC CV LED power supply – block diagram

Mean Well APV-12-24 12W 24V IP42 LED Power Supply

Name: Mean Well APV-12-24 12W 24V IP42 LED Power Supply
Brand: Mean Well
SKU: tm_APV-12-24
Price: 27.63 PLN
Availability: InStock

Minimum order quantity: 1. Order in multiples of 1.

27.63 PLN

Shipment in 1-2 business days

Category: Constant Voltage (CV)

Reference: tm_APV-12-24

Mean Well APV-12-24 is a 12 W, 24 V DC constant-voltage LED power supply rated at 500 mA.

Volume discounts

Quantity	Discounted price
5+	26.01 PLN
10+	25.20 PLN
20+	23.57 PLN

Quantity

Wishlist

Compare

Delivery

1-3 dni (PL), 3-10 dni (non-PL)

Return Policy

14 days

Description
Product Details

APV-12-24 – full product specification

Mean Well APV-12-24 is a APV-12-series power supply rated at 12 W. The parameters below come from the exact official manufacturer datasheet.

Constant-voltage output

The model supplies loads at 24 V DC with a rated output current of 500 mA.

Full technical specifications

Fully isolated enclosure	Yes
Enclosure material	plastic
Cooling	free-air convection
Dimensions	77 × 40 × 29 mm
Document revision	APV-12-SPEC 2025-12-12
Typical efficiency	84 %
hold_up_time	230 vac ms: 20; 115 vac ms: 15
Input frequency	47–63 Hz
Input range	90–264 VAC / 127–370 VDC
Inrush current	70 A
Insulation resistance	100 MΩ
IP rating	IP42
Leakage current	0.25 mA
Operating temperature	-30–70 °C
Rated current	500 mA
Operating mode	Constant Voltage (CV)
Output voltage	24 V
Over-voltage protection range	27.6–32.4 V
Over-voltage protection	Yes
Short-circuit protection	Yes
Rated power	12 W
Manufacturer warranty	2 years
Weight	0.08 kg

Manufacturer datasheet

Complete source specification: official Mean Well datasheet.

Manufacturer information: Mean Well states that the APV-12 series is not intended for LED lighting luminaire applications in the EU and China; the manufacturer recommends the LPF, NPF, XLG, XLC or XLN series.
