Mean Well HDR-30-48 36W 48V LED Power Supply

Name: Mean Well HDR-30-48 36W 48V LED Power Supply
Brand: Mean Well
SKU: tm_HDR-30-48
Price: 66.66 PLN
Availability: InStock

Minimum order quantity: 1. Order in multiples of 1.

66.66 PLN

Shipment in 1-2 business days

Reference: tm_HDR-30-48

Mean Well HDR-30-48 is a 36 W, 48 V DC constant-voltage power supply for mounting on TS-35/7.5 or TS-35/15 DIN rail.

Volume discounts

Quantity

Delivery

1-3 dni (PL), 3-10 dni (non-PL)

Return Policy

14 days

HDR-30-48 – full product specification

Mean Well HDR-30-48 is a HDR-30-series power supply rated at 36 W. The parameters below come from the exact official manufacturer datasheet.

The supply operates in CV mode. Its output can be set across 43.2 V–55.2 V, and the enclosure mounts on TS-35/7.5 or TS-35/15 DIN rail.

Cooling	free-air convection
Dimensions	35 × 90 × 54.5 mm
Document revision	HDR-30-SPEC 2026-04-03
Typical efficiency	90 %
hold_up_time	230 vac ms: 30; 115 vac ms: 12
Input frequency	47–63 Hz
Input range	85–264 VAC / 120–370 VDC
Inrush current	25 A
Mounting	TS-35/7.5 or TS-35/15 DIN rail
Operating temperature	-30–70 °C
Rated current	750 mA
Operating mode	Constant Voltage (CV)
Maximum adjusted voltage	55.2 V
Minimum adjusted voltage	43.2 V
Output voltage	48 V
Over-voltage protection range	57.6–67.2 V
Over-voltage protection	Yes
Rated power	36 W
Manufacturer warranty	3 years
Weight	0.13 kg
Withstand voltage	4 kVAC
