Mean Well SLD-80-12 79.2 W CV+CC LED driver
Mean Well SLD-80-12 is a 79.2 W CV+CC LED driver with a 8.4 V–12 V constant-current region.
Mean Well SLD-80-12 79.2 W CV+CC LED driver
Minimum order quantity: 1. Order in multiples of 1.
113.81 PLN
Shipment in 1-2 business days
tm_SLD-80-12
Mean Well SLD-80-12 is a 79.2 W CV+CC LED driver with a 8.4 V–12 V constant-current region.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
SLD-80-12 – full product specification
Mean Well SLD-80-12 is a SLD-80-series power supply rated at 79.2 W. The parameters below come from the exact official manufacturer datasheet.
CV+CC operation
The driver combines voltage regulation and current limiting; its constant-current region is 8.4 V–12 V DC.
Full technical specifications
| current_ripple_pct | 5 % |
|---|---|
| Dimensions | 320 × 30 × 16.8 mm |
| Document revision | SLD-80-SPEC 2026-02-09 |
| Typical efficiency | 90.5 % |
| hold_up_time | 230 vac ms: 10; 115 vac ms: 10 |
| Input frequency | 47–63 Hz |
| Input range | 110–305 VAC / 155–431 VDC |
| Inrush current | 50 A |
| Rated current | 6600 mA |
| Operating mode | Constant voltage + constant current (CV+CC) |
| CC-region maximum voltage | 12 V |
| CC-region minimum voltage | 8.4 V |
| Output voltage | 12 V |
| Over-voltage protection range | 14–17 V |
| Over-voltage protection | Yes |
| Short-circuit protection | Yes |
| Rated power | 79.2 W |
| Manufacturer warranty | 3 years |
Manufacturer datasheet
Complete source specification: official Mean Well datasheet.
tm_SLD-80-12
Data sheet
- Power supply type
- CV+CC
- Rated power [W]
- 60,1-100
- Output Current of CC power supply [mA]
- 6600
- CC operating window
- 8.4-12
- Min. output voltage of led driver (CC)
- 8.4
- Max. output voltage of led driver (CC)
- 12
- Length [mm]
- 320
- Width [mm]
- 30
- Height/thickness [mm]
- 16.8
- Warranty [years]
- 3
- Input voltage [V]
- 110-305
Specific References
- EAN13
- 4711287457604
- MPN
- SLD-80-12
