LED power supply Tridonic LCI 150W 2100mA TEC C
LED power supply Tridonic LCI 150W 2100mA TEC C is a constant current LED driver rated up to 150 W. Values for individual settings are shown in the operating-point table.Load selection depends on the applicable operating window.
LED power supply Tridonic LCI 150W 2100mA TEC C
370.00 PLN
Shipment in 8-10 working days
zas_tridonic_87500271
LED power supply Tridonic LCI 150W 2100mA TEC C is a constant current LED driver rated up to 150 W. Values for individual settings are shown in the operating-point table.Load selection depends on the applicable operating window.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
LED power supply Tridonic LCI 150W 2100mA TEC C is a constant current LED driver in the Driver LCI 150W 1750/2100/2450mA TEC C family. Official article number 87500271 identifies this physical version.
Key properties
Common and exact-article specifications are kept separate from operating points. Power, LED voltage, efficiency and temperatures may depend on settings and load; the complete multi-row manufacturer data is shown below.
Technical specifications
| Manufacturer article number | 87500271 |
|---|---|
| Manufacturer family | Driver LCI 150W 1750/2100/2450mA TEC C |
| Manufacturer product group | Compact drivers |
| Supply voltage | 220 – 240 V |
| AC voltage range | 198 – 264 V |
| Mains frequency | 50 / 60 Hz |
| Overvoltage protection | 300 V AC, 1 h |
| THD (at 230 V, 50 Hz, min. load) | <20 % |
| THD at 230V, full load | <10 % |
| Starting time | ≤0.5 s |
| Turn off time | ≤0.5 s |
| Hold on time | 0 s |
| Output LF current ripple (< 120 Hz) / Current ripple at full load | <3 % |
| Output P_ST_LM (at full load) | ≤1 |
| Output SVM (at full load) | ≤0.4 |
| Storage temperature ts | -40–80 °C |
| Guarantee | 5 years |
| Output current | 2100 mA |
| Typ. current (at 230 V, 50 Hz, full load) | 700 mA |
| Min./Max. forward voltage | 35.5 V; 71.5 V |
| Max. output voltage | 76 V |
| Typ. output power | 150 W |
| Output power range | 75–150 W |
| Power Consumption | 158.5 W; 170 W |
| Efficiency at min./full load | 91 %; 94 % |
| λ over full operating range (max.) | 0.99 |
| λ over full operating range (min.) | 0.95 |
| Output current tolerance, min./full load | ±7.5 % |
| Max. repetitive output peak current | 3150 mA |
| Ambient temperature ta | 60 °C; -25–60 °C |
| Max. casing temperature tc | 95 °C |
| Lifetime | up to 50000 h |
| Length | 140 mm |
| Width | 100 mm |
| Height | 30 mm |
| Output mode | CC |
| Maximum output power [W] | 150 |
| Input voltage | 220 – 240 V |
| Warranty [years] | 5 |
| Maximum casing temperature tc | 95 °C |
| Storage temperature | -40–80 °C |
| THD | <10 % |
| λ over full operating range (max.) | 0.99 |
| Dimensions L×W×H | 140 × 100 × 30 mm |
| Lifetime [h] | up to 50000 h |
| Product net weight | 0.328 kg |
| short_circuit_protection | Yes |
| overload_protection | Yes |
| no_load_protection | Yes |
| Manufacturer note: Product description | Fixed output built-in LED driver |
| Manufacturer note: Product description | Constant current LED driver |
| Manufacturer note: Product description | Output current 1,750, 2,100 or 2,450 mA |
| Manufacturer note: Product description | Max. output power 150 W |
| Manufacturer note: Product description | Nominal lifetime up to 50,000 h |
| Manufacturer note: Product description | For luminaires of protection class I and protection class II |
| Manufacturer note: Product description | Temperature protection as per EN 61347-2-13 C5e |
| Manufacturer note: Product description | Article LCI 150W 2100mA TEC C (87500271) has the KC approval mark. |
| Manufacturer note: Product description | 5 years guarantee (conditions at https://www.tridonic.com/en/int/services/manufacturer-guarantee-conditions) |
| Manufacturer note: Housing properties | Casing: polycarbonate, white |
| Manufacturer note: Housing properties | Brush-coated for higher protection against humidity |
| Manufacturer note: Housing properties | Type of protection IP20 |
| Manufacturer note: Functions | Overtemperature protection |
| Manufacturer note: Functions | Overload protection |
| Manufacturer note: Functions | Short-circuit protection |
| Manufacturer note: Functions | No-load protection |
| Manufacturer note: Functions | Burst protection voltage up to 2 kV |
| Manufacturer note: Functions | Surge protection voltage up to 2 kV (L to N) |
| Manufacturer note: Functions | Surge protection voltage up to 4 kV (L/N to earth) |
Operating points
| Point | Output current | Typ. current (at 230 V, 50 Hz, full load) | Min./Max. forward voltage | Max. output voltage | Typ. output power | Output power range | Power Consumption | Efficiency at min./full load | λ over full operating range (max.) | λ over full operating range (min.) | Output current tolerance, min./full load | Max. repetitive output peak current | Ambient temperature ta | Max. casing temperature tc | Lifetime | Length | Width | Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | 2100 mA | 700 mA | 35.5 V; 71.5 V | 76 V | 150 W | 75–150 W | 158.5 W; 170 W | 91 %; 94 % | 0.99 | 0.95 | ±7.5 % | 3150 mA | 60 °C; -25–60 °C | 95 °C | up to 50000 h | 140 mm | 100 mm | 30 mm |
The Vmin/Vmax and CC operating-window filter features represent the global envelope of all documented settings. The complete operating-point table defines the permitted voltage at each current setting.
Installation / application
Select LED modules by comparing their forward voltage and current with the operating window at the chosen setting. Maximum tc and permissible ambient temperature apply under the conditions stated for each operating point.
Additional information
Warranty and declared lifetime are subject to manufacturer conditions. Other family versions do not establish the contents of this article; assess its exact model designation and assigned photographs together.
Main source of information: www.tridonic.com
We make every effort to ensure that the information presented in this product description is complete, up to date and consistent with source documentation. However, product ranges and specifications may evolve and be updated, and some changes may not yet be reflected in our description. Inaccuracies or errors may also occur in the source documentation itself. If you have any doubts or notice an error, please contact us at bok@ledownia.pl.
zas_tridonic_87500271
Data sheet
- Power supply type
- Constant Current (CC)
- Rated power [W]
- 150
- Output Current of CC power supply [mA]
- 2100
- CC operating window
- 35.5-71.5
- Min. output voltage of led driver (CC)
- 35.5
- Max. output voltage of led driver (CC)
- 71.5
- Dimensions (L x W x H) [mm]
- 140 × 100 × 30 mm
- Length [mm]
- 140
- Width [mm]
- 100
- Height/thickness [mm]
- 30
- Warranty [years]
- 5
- Input voltage [V]
- 220-240
- Min. current of CC driver [mA]
- 2100
- Max. current of CC driver [mA]
- 2100
- Power factor
- 0.99
