LED power supply Tridonic LC 150W 200-1050mA IND sl EXC
LED power supply Tridonic LC 150W 200-1050mA IND sl EXC is a constant current LED driver rated up to 150 W. Values for individual settings are shown in the operating-point table.Load selection depends on the applicable operating window.
LED power supply Tridonic LC 150W 200-1050mA IND sl EXC
400.00 PLN
Shipment in 8-10 working days
zas_tridonic_28000691
LED power supply Tridonic LC 150W 200-1050mA IND sl EXC is a constant current LED driver rated up to 150 W. Values for individual settings are shown in the operating-point table.Load selection depends on the applicable operating window.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
LED power supply Tridonic LC 150W 200-1050mA IND sl EXC is a constant current LED driver in the Driver LC 150W 200–1050mA IND sl EXC (INDUSTRY) family. Official article number 28000691 identifies this physical version.
Key properties
Common and exact-article specifications are kept separate from operating points. Power, LED voltage, efficiency and temperatures may depend on settings and load; the complete multi-row manufacturer data is shown below.
Technical specifications
| Manufacturer article number | 28000691 |
|---|---|
| Manufacturer family | Driver LC 150W 200–1050mA IND sl EXC (INDUSTRY) |
| Manufacturer product group | Linear drivers |
| Supply voltage | 220 – 240 V |
| AC voltage range | 198 – 264 V |
| DC voltage range | 176 – 280 V |
| Mains frequency | 0 / 50 / 60 Hz |
| Overvoltage protection | 320 V AC, 48 h |
| Typ. current (at 230 V, 50 Hz, full load) | 703 mA |
| Typ. current (220 V, 0 Hz, full load, XX % dimming level) | 509 mA |
| Leakage current | <0.25 mA |
| Typ. input current in no-load operation | 61 mA |
| Power Consumption | 158 W |
| Typ. input power in no-load operation | 0.1 W |
| Typ. efficiency at 230 V | 94 % |
| λ over full operating range (max.) | 0.99 |
| THD at 230V, full load | <10 % |
| Starting time | <0.5 s; <0.5 s |
| Switchover time (AC/DC) | <0.2 s |
| Turn off time | <0.05 s |
| Output current tolerance, min./full load | ±5 % |
| Max. output current peak (non-repetitive) + max. peak output current | ≤ output current +35 % |
| Output LF current ripple (< 120 Hz) / Current ripple at full load | ±5 % |
| Output P_ST_LM (at full load) | ≤1 |
| Output SVM (at full load) | ≤0.4 |
| Max. output voltage | 400 V |
| Mains surge capability (between L - N) | 4 kV |
| Mains surge capability (between L/N - PE) | 4 kV |
| Surge voltage at output side (against PE) | 4.5 kV |
| Type of protection | IP20 |
| Length | 360 mm |
| Width | 30 mm |
| Height | 28 mm |
| Lifetime | up to 120000 h |
| Guarantee | 5 years |
| Output mode | CC |
| Maximum output power [W] | 150 |
| Input voltage | 220 – 240 V |
| IP grade | IP20 |
| Warranty [years] | 5 |
| THD | <10 % |
| Typ. efficiency at 230 V | 94 % |
| λ over full operating range (max.) | 0.99 |
| Dimensions L×W×H | 360 × 30 × 28 mm |
| Lifetime [h] | up to 120000 h |
| Product net weight | 0.331 kg |
| short_circuit_protection | Yes |
| overload_protection | Yes |
| no_load_protection | Yes |
| Manufacturer note: Product description | Constant current built-in LED driver, particularly suitable for industrial applications in tough environments such as cold warehouses or factories with elevated ambient temperatures |
| Manufacturer note: Product description | The LED driver is designed for a lifetime stated above under reference conditions and with a failure probability of less than 10 % |
| Manufacturer note: Product description | If being operated up to 50 °C ambient temperature for 100,000 h the LED driver offers a lower failure probability of less than 2.5 % |
| Manufacturer note: Product description | Output current adjustable between 200 – 1,050 mA |
| Manufacturer note: Product description | Max. output power 150 W |
| Manufacturer note: Product description | Suitable for mains voltage peaks (burst/surge) up to 4 kV |
| Manufacturer note: Product description | Expanded temperature range of -40 ... +70 °C |
| Manufacturer note: Product description | Nominal lifetime up to 120,000 h |
| Manufacturer note: Product description | 8 years guarantee (conditions at https://www.tridonic.com/en/int/services/manufacturer-guarantee-conditions) |
| Manufacturer note: Housing properties | White slim metal casing |
| Manufacturer note: Housing properties | Type of protection IP20 |
| Manufacturer note: Interfaces | ready2mains (configuration via mains) |
| Manufacturer note: Functions | Adjustable output current in 1-mA-steps (ready2mains, I-SELECT 2) |
| Manufacturer note: Functions | Protective features (overtemperature, short-circuit, overload, no-load, input voltage range) |
| Manufacturer note: Functions | Suitable for emergency escape lighting systems acc. to EN 50172 |
| Manufacturer note: Functions | Power-up fading at AC |
| Manufacturer note: Functions | Intelligent Temperature Guard (overtemperature protection) |
| Manufacturer note: Functions | Intelligent Voltage Guard (overvoltage and undervoltage monitoring) |
Operating points
| Point | Output current | Min./Max. forward voltage | Typ. current consumption | Output power | Typ. power consumption | Ambient temperature ta | tc point max | i-SELECT resistor value |
|---|---|---|---|---|---|---|---|---|
| 1 | 200.0 mA | 150 V; 300 V | 290 mA | 60 W | 63 W | -40–70 °C | 80.0 °C | — |
| 2 | 250.0 mA | 120 V; 300 V | 353 mA | 75 W | 78 W | -40–70 °C | 80.0 °C | 20 kΩ |
| 3 | 300.0 mA | 100 V; 300 V | 423 mA | 90 W | 94.3 W | -40–70 °C | 80.0 °C | 16.67 kΩ |
| 4 | 350.0 mA | 86 V; 300 V | 487 mA | 105 W | 109.5 W | -40–70 °C | 80.0 °C | 14.29 kΩ |
| 5 | 400.0 mA | 80 V; 300 V | 554 mA | 120 W | 124.9 W | -40–70 °C | 80.0 °C | 12.5 kΩ |
| 6 | 450.0 mA | 80 V; 300 V | 615 mA | 135 W | 139.2 W | -40–70 °C | 85.0 °C | 11.11 kΩ |
| 7 | 500.0 mA | 80 V; 300 V | 686 mA | 150 W | 155.7 W | -40–70 °C | 85.0 °C | 10 kΩ |
| 8 | 550.0 mA | 80 V; 273 V | 703 mA | 150 W | 159.5 W | -40–70 °C | 85.0 °C | 9.09 kΩ |
| 9 | 600.0 mA | 80 V; 250 V | 701 mA | 150 W | 159.3 W | -40–70 °C | 85.0 °C | 8.33 kΩ |
| 10 | 650.0 mA | 80 V; 231 V | 697 mA | 150 W | 158.2 W | -40–70 °C | 85.0 °C | 7.69 kΩ |
| 11 | 700.0 mA | 80 V; 214 V | 695 mA | 150 W | 157.8 W | -40–70 °C | 85.0 °C | 7.14 kΩ |
| 12 | 750.0 mA | 80 V; 200 V | 689 mA | 150 W | 156.4 W | -40–70 °C | 90.0 °C | 6.67 kΩ |
| 13 | 800.0 mA | 80 V; 188 V | 704 mA | 150 W | 159.8 W | -40–70 °C | 90.0 °C | 6.25 kΩ |
| 14 | 850.0 mA | 80 V; 176 V | 696 mA | 150 W | 158.1 W | -40–70 °C | 90.0 °C | 5.88 kΩ |
| 15 | 900.0 mA | 80 V; 167 V | 698 mA | 150 W | 158.4 W | -40–70 °C | 90.0 °C | 5.56 kΩ |
| 16 | 950.0 mA | 80 V; 158 V | 696 mA | 150 W | 158.1 W | -40–70 °C | 90.0 °C | 5.26 kΩ |
| 17 | 1000.0 mA | 80 V; 150 V | 703 mA | 150 W | 159.5 W | -40–70 °C | 90.0 °C | 5 kΩ |
| 18 | 1050.0 mA | 80 V; 143 V | 696 mA | 150 W | 157.8 W | -40–70 °C | 90.0 °C | Short circuit (0 kΩ) |
The Vmin/Vmax and CC operating-window filter features represent the global envelope of all documented settings. The complete operating-point table defines the permitted voltage at each current setting.
Installation / application
Select LED modules by comparing their forward voltage and current with the operating window at the chosen setting. Maximum tc and permissible ambient temperature apply under the conditions stated for each operating point.
Additional information
Warranty and declared lifetime are subject to manufacturer conditions. Other family versions do not establish the contents of this article; assess its exact model designation and assigned photographs together.
Main source of information: www.tridonic.com
We make every effort to ensure that the information presented in this product description is complete, up to date and consistent with source documentation. However, product ranges and specifications may evolve and be updated, and some changes may not yet be reflected in our description. Inaccuracies or errors may also occur in the source documentation itself. If you have any doubts or notice an error, please contact us at bok@ledownia.pl.
zas_tridonic_28000691
Data sheet
- Power supply type
- Constant Current (CC)
- Rated power [W]
- 150
- Output Current of CC power supply [mA]
- 200-1050
- CC operating window
- 80-300
- Min. output voltage of led driver (CC)
- 80
- Max. output voltage of led driver (CC)
- 300
- Dimensions (L x W x H) [mm]
- 360 × 30 × 28 mm
- IP grade
- 20
- Length [mm]
- 360
- Width [mm]
- 30
- Height/thickness [mm]
- 28
- Warranty [years]
- 5
- Input voltage [V]
- 220-240
- Min. current of CC driver [mA]
- 200
- Max. current of CC driver [mA]
- 1050
- Power factor
- 0.99
