Mean Well HLN-80H-30A 81 W 30 V DC adjustable CV+CC LED driver
Mean Well HLN-80H-30A is a 81 W CV+CC LED driver with 30 V V nominal output and 1620 mA–2700 mA current adjustment via internal potentiometers.
Mean Well HLN-80H-30A 81 W 30 V DC adjustable CV+CC LED driver
Minimum order quantity: 1. Order in multiples of 1.
178.85 PLN
Shipment in 1-2 business days
tm_HLN-80H-30A
Mean Well HLN-80H-30A is a 81 W CV+CC LED driver with 30 V V nominal output and 1620 mA–2700 mA current adjustment via internal potentiometers.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
HLN-80H-30A – full product specification
Mean Well HLN-80H-30A is an LED power supply from the HLN-80H series with a 81 W rated output. The verified manufacturer datasheet data below supports correct circuit and operating-condition selection.
CV+CC output and adjustment
The A-type variant has a 30 V DC nominal output. Internal potentiometers adjust voltage across 27–33 V DC and the constant-current level across 1620 mA–2700 mA; the constant-current region is 18–30 V DC.
Input and efficiency
The specified input range is 90–305 VAC / 127–431 VDC. The input frequency range is 47–63 Hz. Manufacturer-specified typical efficiency is 91 %.
Full technical specifications
| Manufacturer | Mean Well |
|---|---|
| Series | HLN-80H |
| Model | HLN-80H-30A |
| Operating mode | Constant voltage + constant current (CV+CC) |
| Rated power | 81 W |
| Nominal output voltage | 30 V |
| Rated output current | 2700 mA |
| Output voltage adjustment range | 27–33 V DC |
| Minimum adjustable current | 1620 mA |
| Maximum adjustable current | 2700 mA |
| Constant-current region | 18–30 V DC |
| Adjustment method | internal potentiometers |
| Input voltage range | 90–305 VAC / 127–431 VDC |
| Input frequency | 47–63 Hz |
| Typical efficiency | 91 % |
| Inrush current | 70 A |
| Short-circuit protection | Yes |
| Over-voltage protection | Yes |
| Cooling | free-air convection |
| IP rating | IP64 |
| Operating temperature | -40–50 °C |
| Dimensions (L × W × H) | 181 × 61.5 × 35 mm |
| Manufacturer warranty | 3 years |
Protection and construction
- Short-circuit protection: Yes
- Over-voltage protection: Yes
- Cooling: free-air convection
- IP rating: IP64
Operating conditions and mechanical data
Operating temperature: -40–50 °C; Dimensions (L × W × H): 181 × 61.5 × 35 mm; Manufacturer warranty: 3 years.
Manufacturer datasheet
The complete source specification is available directly from the manufacturer: Official Mean Well datasheet — HLN-80H-SPEC 2026-02-09.
Manufacturer information: Mean Well states that the HLN-80H series is not intended for LED lighting applications in China; for such applications, the manufacturer recommends the LPF, NPF, XLG, XLC or XLN series.
Manufacturer lifecycle information: Mean Well lists HLN-80H-30A as EOL effective 2026.07 and names LPF-40/60/90 or XLN-40/60 as successor models or families; this does not imply automatic 1:1 electrical interchangeability.
tm_HLN-80H-30A
Data sheet
- Power supply type
- CV+CC
- Rated power [W]
- 60,1-100
- IP grade
- 64
- Case type of power supply
- Waterproof
- Length [mm]
- 181
- Width [mm]
- 61.5
- Height/thickness [mm]
- 35
- Life span [h]
- 100000
- Warranty [years]
- 3
- Input voltage [V]
- 90-305
- Min. current of CC driver [mA]
- 1620
- Max. current of CC driver [mA]
- 2700
Specific References
- MPN
- HLN-80H-30A
