Mean Well TDR-480-48 480W 48V LED Power Supply
Mean Well TDR-480-48 is a 480 W, 48 V DC constant-voltage power supply for mounting on TS-35/7.5 or TS-35/15 DIN rail.
Mean Well TDR-480-48 480W 48V LED Power Supply
Minimum order quantity: 1. Order in multiples of 1.
577.23 PLN
Shipment in 1-2 business days
tm_TDR-480-48
Mean Well TDR-480-48 is a 480 W, 48 V DC constant-voltage power supply for mounting on TS-35/7.5 or TS-35/15 DIN rail.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
TDR-480-48 – full product specification
Mean Well TDR-480-48 is a TDR-480-series power supply rated at 480 W. The parameters below come from the exact official manufacturer datasheet.
Output and mounting
The supply operates in CV mode. Its output can be set across 0 V–0 V, and the enclosure mounts on TS-35/7.5 or TS-35/15 DIN rail.
Full technical specifications
| Dimensions | 85.5 × 125.2 × 128.5 mm |
|---|---|
| Document revision | TDR-480-SPEC 2024-11-22 |
| Typical efficiency | 93 % |
| Mounting | TS-35/7.5 or TS-35/15 DIN rail |
| Rated current | 10000 mA |
| Operating mode | Constant Voltage (CV) |
| Output voltage | 48 V |
| Over-voltage protection range | 56–65 V |
| Over-voltage protection | Yes |
| Rated power | 480 W |
| Weight | 1.51 kg |
| Withstand voltage | 3 kVAC |
Manufacturer datasheet
Complete source specification: official Mean Well datasheet.
tm_TDR-480-48
Data sheet
- Power supply type
- Constant Voltage (CV)
- Rated power [W]
- 250-499
- Output Voltage of CV power supply [V]
- 48
- Length [mm]
- 85.5
- Width [mm]
- 125.2
- Height/thickness [mm]
- 128.5
Specific References
- EAN13
- 4711287422497
- MPN
- TDR-480-48
