Mean Well MDR-100-48 96W 48V LED Power Supply
Mean Well MDR-100-48 is a 96 W, 48 V DC constant-voltage power supply for mounting on TS-35/7.5 or TS-35/15 DIN rail.
Mean Well MDR-100-48 96W 48V LED Power Supply
Minimum order quantity: 1. Order in multiples of 1.
162.59 PLN
Shipment in 1-2 business days
tm_MDR-100-48
Mean Well MDR-100-48 is a 96 W, 48 V DC constant-voltage power supply for mounting on TS-35/7.5 or TS-35/15 DIN rail.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
MDR-100-48 – full product specification
Mean Well MDR-100-48 is a MDR-100-series power supply rated at 96 W. The parameters below come from the exact official manufacturer datasheet.
Output and mounting
The supply operates in CV mode. Its output can be set across 0 V–0 V, and the enclosure mounts on TS-35/7.5 or TS-35/15 DIN rail.
Full technical specifications
| Cooling | free-air convection |
|---|---|
| Dimensions | 55 × 90 × 100 mm |
| Document revision | MDR-100-SPEC 2025-12-12 |
| Typical efficiency | 87 % |
| hold_up_time | 230 vac ms: 50; 115 vac ms: 20 |
| Input frequency | 47–63 Hz |
| Input range | 85–264 VAC / 120–370 VDC |
| Inrush current | 30 A |
| Mounting | TS-35/7.5 or TS-35/15 DIN rail |
| Operating temperature | -10–60 °C |
| Rated current | 2000 mA |
| Operating mode | Constant Voltage (CV) |
| Output voltage | 48 V |
| Over-voltage protection | Yes |
| Short-circuit protection | Yes |
| Rated power | 96 W |
| Manufacturer warranty | 3 years |
| Weight | 0.42 kg |
| Withstand voltage | 3 kVAC |
Manufacturer datasheet
Complete source specification: official Mean Well datasheet.
tm_MDR-100-48
Data sheet
- Power supply type
- Constant Voltage (CV)
- Rated power [W]
- 60,1-100
- Output Voltage of CV power supply [V]
- 48
- Length [mm]
- 55
- Width [mm]
- 90
- Height/thickness [mm]
- 100
- Warranty [years]
- 3
- Input voltage [V]
- 85-264
Specific References
- EAN13
- 4711287422107
- MPN
- MDR-100-48
