Mean Well RS-75-12 72W 12V IP20 LED Power Supply
Mean Well RS-75-12 is a 72 W constant-voltage LED power supply with a 12 V DC output and 6000 mA rated current.
Mean Well RS-75-12 72W 12V IP20 LED Power Supply
Minimum order quantity: 1. Order in multiples of 1.
79.67 PLN
Shipment in 1-2 business days
tm_RS-75-12
Mean Well RS-75-12 is a 72 W constant-voltage LED power supply with a 12 V DC output and 6000 mA rated current.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
RS-75-12 – full product specification
Mean Well RS-75-12 is an LED power supply from the RS-75 series with a 72 W rated output. The verified manufacturer datasheet data below supports correct circuit and operating-condition selection.
Selection and output
Use this model with LED loads designed for a 12 V DC supply. The rated output current is 6000 mA; match the total connected load to the rated output power.
Input and efficiency
The specified input range is 88–264 VAC / 125–373 VDC. Manufacturer-specified typical efficiency is 84.5 %.
Full technical specifications
| Manufacturer | Mean Well |
|---|---|
| Series | RS-75 |
| Model | RS-75-12 |
| Operating mode | Constant Voltage (CV) |
| Rated power | 72 W |
| Output voltage | 12 V |
| Rated output current | 6000 mA |
| Input voltage range | 88–264 VAC / 125–373 VDC |
| Typical efficiency | 84.5 % |
| Inrush current | 40 A |
| Over-voltage protection | Yes |
| Withstand voltage | 3 kVAC |
| Dimensions (L × W × H) | 129 × 98 × 38 mm |
| Technical weight | 0.41 kg |
Protection and construction
- Over-voltage protection: Yes
- Withstand voltage: 3 kVAC
Operating conditions and mechanical data
Dimensions (L × W × H): 129 × 98 × 38 mm; Technical weight: 0.41 kg.
Manufacturer datasheet
The complete source specification is available directly from the manufacturer: Official Mean Well datasheet — RS-75-SPEC 2024-11-22.
tm_RS-75-12
Data sheet
- Power supply type
- Constant Voltage (CV)
- Rated power [W]
- 60,1-100
- Output Voltage of CV power supply [V]
- 12
- Maximum output current of CV led driver
- 6
- Dimensions (L x W x H) [mm]
- 129/98/38
- IP grade
- 20
- Case type of power supply
- Module / perforated case
- Case material
- Metal
- Length [mm]
- 129
- Grounding
- Yes
- Width [mm]
- 98
- Height/thickness [mm]
- 38
- Warranty [years]
- 3
- Input voltage [V]
- 88-264
- Interface
- Screw terminals
Specific References
- MPN
- RS-75-12
