Mean Well DRA-40-24 40.8W 24V LED Power Supply

Name: Mean Well DRA-40-24 40.8W 24V LED Power Supply
Brand: Mean Well
SKU: tm_DRA-40-24
Price: 105.68 PLN
Availability: InStock

Minimum order quantity: 1. Order in multiples of 1.

105.68 PLN

Shipment in 1-2 business days

Reference: tm_DRA-40-24

Mean Well DRA-40-24 is a 40.8 W, 24 V DC constant-voltage power supply for mounting on TS-35/7.5 or TS-35/15 DIN rail.

Volume discounts

Quantity	Discounted price
10+	97.55 PLN

Quantity

Delivery

1-3 dni (PL), 3-10 dni (non-PL)

Return Policy

14 days

DRA-40-24 – full product specification

Mean Well DRA-40-24 is a DRA-40-series power supply rated at 40.8 W. The parameters below come from the exact official manufacturer datasheet.

The supply operates in CV mode. Its output can be set across 0 V–0 V, and the enclosure mounts on TS-35/7.5 or TS-35/15 DIN rail.

Cooling	free-air convection
Dimensions	40 × 90 × 100 mm
Document revision	DRA-40-SPEC 2026-03-31
Typical efficiency	87 %
hold_up_time	230 vac ms: 50; 115 vac ms: 10
Input frequency	47–63 Hz
Input range	90–264 VAC / 127–370 VDC
Inrush current	30 A
Mounting	TS-35/7.5 or TS-35/15 DIN rail
Operating temperature	-30–70 °C
Rated current	1700 mA
Operating mode	Constant Voltage (CV)
CC-region maximum voltage	24 V
CC-region minimum voltage	3 V
Output voltage	24 V
Over-voltage protection range	28.98–37.26 V
Over-voltage protection	Yes
Short-circuit protection	Yes
Rated power	40.8 W
Manufacturer warranty	3 years
Weight	0.3 kg
Withstand voltage	3 kVAC
