LED power supply Tridonic LC 38W 400-700mA flexC lp | LEDownia.pl

LED power supply | Tridonic LC 38/400-700/54 flexC lp SNC4 38W

Name: LED power supply | Tridonic LC 38/400-700/54 flexC lp SNC4 38W
Brand: Tridonic
SKU: zas_tridonic_28004142
Price: 77.23 PLN
Availability: InStock

77.23 PLN

Shipment in 1-2 business days

Category: Constant Current (CC)

Reference: zas_tridonic_28004142

The Tridonic LC 38/400-700/54 flexC lp SNC4 led power supply combines high efficiency with an adjustable 400–700 mA current range. This constant current SELV power supply is ideal for linear luminaires, downlights and area lighting, delivering safe and stable LED operation.

Delivery

1-3 dni (PL), 3-10 dni (non-PL)

Return Policy

14 days

Description
Product Details

LED power supply Tridonic LC 38/400-700/54 flexC lp SNC4 – technical data

Maximum output power	38 W
Output power range	8 – 37.8 W
Output current	400, 450, 500, 550, 600, 650, 700 mA (DIP)
Output voltage	20 – 54 V DC
Maximum output voltage U-OUT	60 V
Type	constant current, SELV, built-in
Typical efficiency	up to 86.5%
Power factor	up to 0.97
THD at full load	< 12%
Supply voltage	220–240 V AC
AC voltage range	198–264 V
DC voltage range	176–280 V
Mains frequency	0 / 50 / 60 Hz
Overvoltage protection	320 V AC, 2 h
Degree of protection	IP20
Housing	ML300, white
Dimensions	180 x 30 x 21 mm
Mounting hole spacing	168 mm
Ambient temperature ta	-20 ... +60 °C
Maximum tc temperature	up to 90 °C (depending on current)
Storage temperature	-40 ... +80 °C
Starting time	≤ 0.5 s (AC), ≤ 0.6 s (DC)
Turn off time	≤ 0.5 s
Protections	overload, short-circuit, no-load
Protection class	for class I and class II luminaires
Nominal lifetime	up to 100,000 h
Manufacturer guarantee	5 years
Weight	0.128 kg
Product website	http://www.tridonic.com/28004142

LED power supply – flexible output current setting

This led power supply from Tridonic offers seven selectable output currents between 400 and 700 mA. The current is set via a three pin DIP switch with mains disconnected. This allows easy matching to many constant current LED modules. The default 700 mA setting simplifies installation in standard linear and downlight applications. One power supply can cover several projects and reduce stock complexity.

LED power supply – high efficiency and stable performance

The LC 38/400-700/54 flexC lp SNC4 led power supply delivers efficiency up to 86.5% at full load. A high power factor and controlled THD help reduce stress on the electrical installation. Low output ripple improves visual comfort and extends LED module lifetime. The power supply complies with key EMC and safety standards. Stable operation is ensured with both AC and DC supply in normal or emergency modes.

LED power supply – safety and reliability inside the luminaire

The led power supply is designed for built in use in luminaires, including linear, downlight, spotlight and area fittings. SELV design and robust ML300 housing make safe luminaire construction easier. Integrated protection against overload, short circuit and no load protects both the power supply and the LED modules. The unit supports use in central battery and emergency lighting systems according to relevant standards. A rated lifetime up to 100,000 hours and a five year guarantee make it a strong choice for demanding commercial lighting projects.
