Mean Well HBG-160-24DA 156 W CV+CC LED driver
Mean Well HBG-160-24DA is a 156 W CV+CC LED driver with a 14.4 V–24 V constant-current region.
Mean Well HBG-160-24DA 156 W CV+CC LED driver
Minimum order quantity: 1. Order in multiples of 1.
308.93 PLN
Shipment in 8-10 working days
tm_HBG-160-24DA
Mean Well HBG-160-24DA is a 156 W CV+CC LED driver with a 14.4 V–24 V constant-current region.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
HBG-160-24DA – full product specification
Mean Well HBG-160-24DA is a HBG-160-series power supply rated at 156 W. The parameters below come from the exact official manufacturer datasheet.
CV+CC operation
The driver combines voltage regulation and current limiting; its constant-current region is 14.4 V–24 V DC.
Full technical specifications
| DALI control | Yes |
|---|---|
| 3-in-1 dimming | Yes |
| Document revision | HBG-160-SPEC 2026-06-15 |
| Typical efficiency | 92 % |
| Input frequency | 47–63 Hz |
| Input range | 90–305 VAC / 127–417 VDC |
| Inrush current | 65 A |
| IP rating | IP65 |
| Rated current | 6500 mA |
| Operating mode | Constant voltage + constant current (CV+CC) |
| CC-region maximum voltage | 24 V |
| CC-region minimum voltage | 14.4 V |
| Output voltage | 24 V |
| Over-voltage protection | Yes |
| Short-circuit protection | Yes |
| Rated power | 156 W |
| Manufacturer warranty | 5 years |
| Weight | 1.53 kg |
Manufacturer datasheet
Complete source specification: official Mean Well datasheet.
tm_HBG-160-24DA
Data sheet
- Power supply type
- CV+CC
- Rated power [W]
- 100,1-249
- Output Current of CC power supply [mA]
- 6500
- CC operating window
- 14.4-24
- Min. output voltage of led driver (CC)
- 14.4
- Max. output voltage of led driver (CC)
- 24
- IP grade
- 65
- Warranty [years]
- 5
- Input voltage [V]
- 90-305
Specific References
- EAN13
- 4711287447636
- MPN
- HBG-160-24DA
