LED power supply Tridonic LCO 60W 200-1050mA 100V o4a NF C EXC3

Dimensional drawing LCO 60W 200-1050mA 100V o4a NF C EXC3

LED power supply Tridonic LCO 60/200-1050/100 o4a NF C EXC3

Name: LED power supply Tridonic LCO 60/200-1050/100 o4a NF C EXC3
Brand: Tridonic
SKU: zas_tridonic_28003168
Price: 406.5 PLN
Availability: BackOrder

406.50 PLN

Shipment in 8-10 working days

Category: Dimmable

Reference: zas_tridonic_28003168

LED power supply Tridonic LCO 60W 200-1050mA 100V o4a NF C EXC3 is a constant current LED driver rated up to 60 W. Values for individual settings are shown in the operating-point table. Documented interfaces and configuration methods: DALI, NFC, switchDIM.

Volume discounts

Quantity	Discounted price
10+

Quantity

Wishlist

Compare

The minimum purchase order quantity for the product is 5.

Delivery

1-3 dni (PL), 3-10 dni (non-PL)

Return Policy

14 days

Description
Product Details

LED power supply Tridonic LCO 60W 200-1050mA 100V o4a NF C EXC3 is a constant current LED driver in the Driver LCO 60W 200–1050mA 100V o4a NF C EXC3 family. Official article number 28003168 identifies this physical version.

Key properties

Common and exact-article specifications are kept separate from operating points. Power, LED voltage, efficiency and temperatures may depend on settings and load; the complete multi-row manufacturer data is shown below.

Technical specifications

Manufacturer article number	28003168
Manufacturer family	Driver LCO 60W 200–1050mA 100V o4a NF C EXC3
Manufacturer product group	Compact drivers
Supply voltage	220 – 240 V
AC voltage range	198 – 264 V
InputDIM voltage range	170–250 V
DC voltage range	176 – 280 V
Mains frequency	0 / 50 / 60 Hz
Overvoltage protection	320 V AC, 48 h
Typ. current (at 230 V, 50 Hz, full load)	77–289 mA
Typ. current (220 V, 0 Hz, full load, XX % dimming level)	15–54 mA
Leakage current	<0.325 mA
Touch current (equipotential connected)	480 µA
Power Consumption	68 W
Typ. power input on stand-by 230 V	<0.16 W
Output power range	9.6–60 W
Typ. efficiency at 230 V	92 %
λ over full operating range (max.)	0.97
THD at 230V, full load	<8 %
Starting time	<0.8 s; <0.75 s
Switchover time (AC/DC)	<0.3 s
Turn off time	<0.5 s
Output current tolerance, min./full load	±3 %
Max. output current peak (non-repetitive) + max. peak output current	≤ output current +15 %
Output LF current ripple (< 120 Hz) / Current ripple at full load	±3.3 %
Output P_ST_LM (at full load)	≤1
Output SVM (at full load)	≤0.4
Max. output voltage	130 V; 80 V; 130 V
Dimming range	5–100 %
Mains surge capability (between L - N)	6 kV / 3 kA
Mains surge capability (between L/N - PE)	10 kV; 6 kV
Burst protection	6 kV
Surge voltage at output side (against PE)	<1 kV
Type of protection	IP20
Length	133 mm
Width	77 mm
Height	31 mm
Lifetime	up to 100000 h
Guarantee	8 years
Output mode	CC
Maximum output power [W]	60
Input voltage	220 – 240 V
IP grade	IP20
Warranty [years]	8
THD	<8 %
Typ. efficiency at 230 V	92 %
λ over full operating range (max.)	0.97
Dimensions L×W×H	133 × 77 × 31 mm
Lifetime [h]	up to 100000 h
Product net weight	0.242 kg
Interfaces and configuration	DALI, NFC, switchDIM
Dimming / control	DALI, switchDIM
Dimming	Yes
Configuration method	NFC
short_circuit_protection	Yes
overload_protection	Yes
no_load_protection	Yes
Manufacturer note: Product description	NEW: lumDATA (DALI-2 part ext. 251, 252 and 253)
Manufacturer note: Product description	Dimmable built-in constant current outdoor LED driver
Manufacturer note: Product description	Dimming range 5 – 100 % (min. 10 mA)
Manufacturer note: Product description	For luminaires of protection class I and protection class II
Manufacturer note: Product description	Temperature protection as per EN 61347-2-13 C5e
Manufacturer note: Product description	Output current adjustable between 200 – 1,050 mA via NFC, DALI or ready2mains Programmer
Manufacturer note: Product description	Max. output power 60 W
Manufacturer note: Product description	Up to 92 % efficiency
Manufacturer note: Product description	Lowest power input on stand-by < 0.16 W
Manufacturer note: Product description	Article number 28003168: Made in Europe, article number 87500710: Made in China.
Manufacturer note: Product description	BIS approval mark for art. no.: 87500710
Manufacturer note: Product description	Nominal lifetime of 100,000 h and 8 years guarantee (conditions at https://www.tridonic.com/en/int/services/manufacturer-guarantee-conditions)
Manufacturer note: Interfaces	Near field communication (NFC)
Manufacturer note: Interfaces	one4all (DALI-2 DT 6, DSI, switchDIM, corridorFUNCTION)
Manufacturer note: Interfaces	ready2mains (configuration via mains)
Manufacturer note: Interfaces	U6Me2 (configuration of chronoSTEP via mains and ready2mains Programmer)
Manufacturer note: Interfaces	Terminal blocks: 45° / 0° push terminals
Manufacturer note: Functions	Adjustable output current in 1-mA-steps (NFC, DALI, ready2mains)
Manufacturer note: Functions	Programmable chronoSTEP: times and levels (NFC, DALI, U6Me2)
Manufacturer note: Functions	Fulfills DALI-2 parts: 251 (Luminaire data), 252 (Energy reporting) and 253 (Diagnostics & Maintenance)
Manufacturer note: Functions	Dimming through mains voltage (inputDIM)
Manufacturer note: Functions	Enhanced constant light output function (eCLO)
Manufacturer note: Functions	Protective features (overtemperature, short-circuit, overload, no-load, input voltage range, reduced surge amplification)
Manufacturer note: Functions	Configurable external temperature management (ETM)
Manufacturer note: Functions	Intelligent Temperature Guard (ITG)
Manufacturer note: Functions	Intelligent Voltage Guard Plus (IVG+)
Manufacturer note: Functions	Suitable for emergency escape lighting systems acc. to EN 50172
Manufacturer note: Benefits	Flexible configuration via companionSUITE (NFC, DALI, ready2mains™) or U6Me2 programmer
Manufacturer note: Benefits	Application-oriented operating window for maximum compatibility
Manufacturer note: Benefits	Best energy savings due to low stand-by losses and high efficiency
Manufacturer note: Benefits	In-field programming possible after installation with NFC interface and ready2mains
Manufacturer note: Benefits	High overvoltage protection: up to 10 kV asymmetric (protection class I and II)
Manufacturer note: Benefits	Integrated ESD protection
Manufacturer note: Typical applications	Road, street and industry

Operating points

Point	Output current	Min./Max. forward voltage	Typ. current consumption	Output power	Typ. power consumption	Ambient temperature ta	tc point max	Operating modes / Grouping
1	200.0 mA	48 V; 100 V	116 mA	20 W	24.3 W	-40–70 °C	95.0 °C	High voltage output (HV)
2	250.0 mA	47 V; 100 V	143 mA	25 W	30.2 W	-40–70 °C	95.0 °C	High voltage output (HV)
3	300.0 mA	47 V; 100 V	162 mA	30 W	34.7 W	-40–65 °C	90.0 °C	High voltage output (HV)
4	350.0 mA	47 V; 100 V	182 mA	35 W	40.6 W	-40–60 °C	85.0 °C	High voltage output (HV)
5	400.0 mA	47 V; 100 V	202 mA	40 W	45.4 W	-40–60 °C	85.0 °C	High voltage output (HV)
6	450.0 mA	47 V; 100 V	228 mA	45 W	51.5 W	-40–55 °C	80.0 °C	High voltage output (HV)
7	500.0 mA	47 V; 100 V	247 mA	50 W	60 W	-40–55 °C	80.0 °C	High voltage output (HV)
8	550.0 mA	47 V; 100 V	275 mA	55 W	62.4 W	-40–55 °C	85.0 °C	High voltage output (HV)
9	600.0 mA	47 V; 100 V	293 mA	60 W	66.5 W	-40–55 °C	85.0 °C	High voltage output (HV)
10	650.0 mA	47 V; 92.3 V	290 mA	60 W	66 W	-40–55 °C	85.0 °C	High voltage output (HV)
11	700.0 mA	47 V; 85.7 V	290 mA	60 W	65.9 W	-40–55 °C	85.0 °C	High voltage output (HV)
12	750.0 mA	47 V; 80 V	290 mA	60 W	66 W	-40–55 °C	85.0 °C	High voltage output (HV)
13	800.0 mA	47 V; 75 V	289 mA	60 W	65.5 W	-40–55 °C	85.0 °C	High voltage output (HV)
14	850.0 mA	47 V; 70.6 V	288 mA	60 W	65.4 W	-40–55 °C	85.0 °C	High voltage output (HV)
15	900.0 mA	47 V; 66.7 V	289 mA	60 W	65.7 W	-40–55 °C	85.0 °C	High voltage output (HV)
16	950.0 mA	47 V; 63.2 V	289 mA	60 W	65.7 W	-40–55 °C	85.0 °C	High voltage output (HV)
17	1000.0 mA	47 V; 60 V	289 mA	60 W	65.6 W	-40–55 °C	85.0 °C	High voltage output (HV)
18	1050.0 mA	47 V; 57.1 V	289 mA	60 W	65.6 W	-40–55 °C	85.0 °C	High voltage output (HV)
19	200.0 mA	48 V; 59 V	77 mA	11.8 W	15.6 W	-40–70 °C	90.0 °C	Low voltage output (LV)
20	250.0 mA	38.4 V; 59 V	90 mA	14.8 W	18.9 W	-40–70 °C	90.0 °C	Low voltage output (LV)
21	300.0 mA	32 V; 59 V	103 mA	17.7 W	22.1 W	-40–70 °C	90.0 °C	Low voltage output (LV)
22	350.0 mA	28 V; 59 V	116 mA	20.7 W	25.1 W	-40–70 °C	90.0 °C	Low voltage output (LV)
23	400.0 mA	28 V; 59 V	128 mA	23.6 W	27.9 W	-40–70 °C	90.0 °C	Low voltage output (LV)
24	450.0 mA	28 V; 59 V	142 mA	26.6 W	31.3 W	-40–65 °C	90.0 °C	Low voltage output (LV)
25	500.0 mA	28 V; 59 V	156 mA	29.5 W	34.5 W	-40–65 °C	90.0 °C	Low voltage output (LV)
26	550.0 mA	28 V; 59 V	171 mA	32.5 W	38.1 W	-40–60 °C	85.0 °C	Low voltage output (LV)
27	600.0 mA	28 V; 59 V	182 mA	35.4 W	40.8 W	-40–60 °C	85.0 °C	Low voltage output (LV)
28	650.0 mA	28 V; 59 V	196 mA	38.4 W	44 W	-40–60 °C	85.0 °C	Low voltage output (LV)
29	700.0 mA	28 V; 59 V	209 mA	41.3 W	47.1 W	-40–60 °C	85.0 °C	Low voltage output (LV)
30	750.0 mA	28 V; 59 V	223 mA	44.3 W	50.3 W	-40–55 °C	85.0 °C	Low voltage output (LV)
31	800.0 mA	28 V; 59 V	238 mA	47.2 W	53.7 W	-40–55 °C	85.0 °C	Low voltage output (LV)
32	850.0 mA	28 V; 59 V	247 mA	50.2 W	55.9 W	-40–55 °C	85.0 °C	Low voltage output (LV)
33	900.0 mA	28 V; 59 V	260 mA	53.1 W	59 W	-40–55 °C	85.0 °C	Low voltage output (LV)
34	950.0 mA	28 V; 59 V	274 mA	56.1 W	62.3 W	-40–55 °C	85.0 °C	Low voltage output (LV)
35	1000.0 mA	28 V; 59 V	287 mA	59 W	65.2 W	-40–55 °C	85.0 °C	Low voltage output (LV)
36	1050.0 mA	28 V; 57.1 V	287 mA	60 W	65.2 W	-40–55 °C	85.0 °C	Low voltage output (LV)

The Vmin/Vmax and CC operating-window filter features represent the global envelope of all documented settings. The complete operating-point table defines the permitted voltage at each current setting.

Installation / application

Select LED modules by comparing their forward voltage and current with the operating window at the chosen setting. Maximum tc and permissible ambient temperature apply under the conditions stated for each operating point.

Additional information

Warranty and declared lifetime are subject to manufacturer conditions. Other family versions do not establish the contents of this article; assess its exact model designation and assigned photographs together.

Main source of information: www.tridonic.com
