LED power supply Tridonic LCO 240/200-1400 flexC 0-10V NF L SNC3
LED power supply Tridonic LCO 240/200-1400 flexC 0-10V NF L SNC3 is a constant current LED driver rated up to 240 W. Values for individual settings are shown in the operating-point table. Documented interfaces and configuration methods: NFC.
LED power supply Tridonic LCO 240/200-1400 flexC 0-10V NF L SNC3
583.00 PLN
Shipment in 8-10 working days
zas_tridonic_28003559
LED power supply Tridonic LCO 240/200-1400 flexC 0-10V NF L SNC3 is a constant current LED driver rated up to 240 W. Values for individual settings are shown in the operating-point table. Documented interfaces and configuration methods: NFC.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
LED power supply Tridonic LCO 240/200-1400 flexC 0-10V NF L SNC3 is a constant current LED driver in the Driver LCO 240W 200–1400mA flexC 0-10V NF L SNC3 family. Official article number 28003559 identifies this physical version.
Key properties
Common and exact-article specifications are kept separate from operating points. Power, LED voltage, efficiency and temperatures may depend on settings and load; the complete multi-row manufacturer data is shown below.
Technical specifications
| Manufacturer article number | 28003559 |
|---|---|
| Manufacturer family | Driver LCO 240W 200–1400mA flexC 0-10V NF L SNC3 |
| Manufacturer product group | Linear drivers |
| Supply voltage | 100 – 277 V |
| AC voltage range | 90 – 305 V |
| Mains frequency | 50 / 60 Hz |
| Typ. current (at 230 V, 50 Hz, full load) | 1270 mA |
| Leakage current | <0.75 mA |
| Typ. input current in no-load operation | 64 mA |
| Power Consumption | 280 W |
| Typ. power input on stand-by 230 V | <0.39 W |
| Typ. input power in no-load operation | 3.2 W |
| Typ. efficiency at 230 V | 91 % |
| λ over full operating range (max.) | 0.95 |
| THD at 230V, full load | <10 % |
| Starting time | ≤0.5 s |
| Turn off time | <0.03 s |
| Hold on time | <0.02 s |
| Output current tolerance, min./full load | ±5 % |
| Max. output current peak (non-repetitive) + max. peak output current | ≤ output current +10 % |
| Output LF current ripple (< 120 Hz) / Current ripple at full load | ±5 % |
| Output P_ST_LM (at full load) | ≤1 |
| Output SVM (at full load) | ≤0.4 |
| Max. output voltage | 530 V |
| Dimming range | 1–100 % |
| Mains surge capability (between L - N) | 6 kV |
| Mains surge capability (between L/N - PE) | 10 kV |
| Surge voltage at output side (against PE) | 2 kV |
| Type of protection | IP67 |
| Length | 283 mm |
| Width | 61 mm |
| Height | 37.8 mm |
| Lifetime | up to 50000 h |
| Guarantee | 5 years |
| Output mode | CC |
| Maximum output power [W] | 240 |
| Input voltage | 100 – 277 V |
| IP grade | IP67 |
| Warranty [years] | 5 |
| THD | <10 % |
| Typ. efficiency at 230 V | 91 % |
| λ over full operating range (max.) | 0.95 |
| Dimensions L×W×H | 283 × 61 × 37.8 mm |
| Lifetime [h] | up to 50000 h |
| Product net weight | 1.31 kg |
| Interfaces and configuration | NFC |
| Dimming | Yes |
| Configuration method | NFC |
| short_circuit_protection | Yes |
| overload_protection | Yes |
| no_load_protection | Yes |
| Manufacturer note: Product description | Constant current LED driver |
| Manufacturer note: Product description | Tested acc. to salt spray test (ISO 9227) |
| Manufacturer note: Product description | Dimmable via 0 ... 10 V interface (incl. stand-by) |
| Manufacturer note: Product description | Dimming range 1 to 100 % |
| Manufacturer note: Product description | Adjustable output current between 200 and 1,400 mA with NFC |
| Manufacturer note: Product description | Max. output power 240 W |
| Manufacturer note: Product description | Up to 91 % efficiency |
| Manufacturer note: Product description | Nominal lifetime up to 50,000 h |
| Manufacturer note: Product description | 5 years guarantee (conditions at https://www.tridonic.com/en/int/services/manufacturer-guarantee-conditions) |
| Manufacturer note: Housing properties | Casing: metal, black |
| Manufacturer note: Housing properties | Type of protection IP67 and IP66 |
| Manufacturer note: Functions | Adjustable output current in 1-mA-steps (NFC) |
| Manufacturer note: Functions | AUX output |
| Manufacturer note: Functions | Fade-off time programmable |
| Manufacturer note: Functions | Configurable external temperature management (ETM) |
| Manufacturer note: Functions | Protective features (overtemperature, short-circuit, overload, no-load) |
| Manufacturer note: Benefits | Operating window for maximum compatibility |
| Manufacturer note: Benefits | Added energy savings with dimming via 0 .... 10 V interface |
| Manufacturer note: Benefits | Configurable via NFC |
| Manufacturer note: Benefits | Tailor your dimming response with either Linear, Logarithmic or Square Dimming Curves |
| Manufacturer note: Typical applications | For parking lot, high bay, street and road applications |
| Manufacturer note: Typical applications | For linear or area lighting in industry applications |
Operating points
| Point | Output current | Min./Max. forward voltage | Typ. current consumption | Output power | Typ. power consumption | Ambient temperature ta | tc point max |
|---|---|---|---|---|---|---|---|
| 1 | 200.0 mA | 81 V; 450 V | 471 mA | 90 W | 104.8 W | -40–60 °C | 90.0 °C |
| 2 | 500.0 mA | 81 V; 450 V | 1064 mA | 225 W | 244.2 W | -40–60 °C | 90.0 °C |
| 3 | 800.0 mA | 81 V; 300 V | 1121 mA | 240 W | 257.5 W | -40–60 °C | 90.0 °C |
| 4 | 1100.0 mA | 81 V; 218.2 V | 1124 mA | 240 W | 258 W | -40–60 °C | 90.0 °C |
| 5 | 1400.0 mA | 81 V; 171.4 V | 1138 mA | 240 W | 261.2 W | -40–60 °C | 90.0 °C |
The Vmin/Vmax and CC operating-window filter features represent the global envelope of all documented settings. The complete operating-point table defines the permitted voltage at each current setting.
Installation / application
Select LED modules by comparing their forward voltage and current with the operating window at the chosen setting. Maximum tc and permissible ambient temperature apply under the conditions stated for each operating point.
Additional information
Warranty and declared lifetime are subject to manufacturer conditions. Other family versions do not establish the contents of this article; assess its exact model designation and assigned photographs together.
Main source of information: www.tridonic.com
We make every effort to ensure that the information presented in this product description is complete, up to date and consistent with source documentation. However, product ranges and specifications may evolve and be updated, and some changes may not yet be reflected in our description. Inaccuracies or errors may also occur in the source documentation itself. If you have any doubts or notice an error, please contact us at bok@ledownia.pl.
zas_tridonic_28003559
Data sheet
- Power supply type
- Constant Current (CC)
- Rated power [W]
- 240
- Output Current of CC power supply [mA]
- 200-1400
- CC operating window
- 81-450
- Min. output voltage of led driver (CC)
- 81
- Max. output voltage of led driver (CC)
- 450
- Dimensions (L x W x H) [mm]
- 283 × 61 × 37.8 mm
- IP grade
- 67
- Length [mm]
- 283
- Width [mm]
- 61
- Height/thickness [mm]
- 37.8
- Warranty [years]
- 5
- Input voltage [V]
- 100-277
- Min. current of CC driver [mA]
- 200
- Max. current of CC driver [mA]
- 1400
- Power factor
- 0.95
