LED power supply Tridonic LCO 110/200-1050/157 cS NF C SNC
LED power supply Tridonic LCO 110W 200-1050mA 157V cS NF C SNC is a constant current LED driver rated up to 110 W. Values for individual settings are shown in the operating-point table. Documented interfaces and configuration methods: NFC.
LED power supply Tridonic LCO 110/200-1050/157 cS NF C SNC
260.00 PLN
Shipment in 8-10 working days
zas_tridonic_87501194
LED power supply Tridonic LCO 110W 200-1050mA 157V cS NF C SNC is a constant current LED driver rated up to 110 W. Values for individual settings are shown in the operating-point table. Documented interfaces and configuration methods: NFC.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
LED power supply Tridonic LCO 110W 200-1050mA 157V cS NF C SNC is a constant current LED driver in the Driver LCO 110W 200–1050mA 157V cS NF C SNC family. Official article number 87501194 identifies this physical version.
Key properties
Common and exact-article specifications are kept separate from operating points. Power, LED voltage, efficiency and temperatures may depend on settings and load; the complete multi-row manufacturer data is shown below.
Technical specifications
| Manufacturer article number | 87501194 |
|---|---|
| Manufacturer family | Driver LCO 110W 200–1050mA 157V cS NF C SNC |
| Manufacturer product group | Compact drivers |
| Supply voltage | 220 – 240 V |
| AC voltage range | 198 – 264 V |
| Mains frequency | 50 / 60 Hz |
| Overvoltage protection | 320 V AC, 48 h |
| Typ. current (at 230 V, 50 Hz, full load) | 525 mA |
| Leakage current | <0.7 mA |
| Touch current (equipotential connected) | 550 µA |
| Power Consumption | 120 W |
| Output power range | 9.6–110 W |
| Typ. efficiency at 230 V | 92 % |
| λ over full operating range (max.) | 0.98 |
| λ over full operating range (min.) | 0.4C |
| THD at 230V, full load | <10 % |
| Starting time | <0.5 s |
| Turn off time | <0.5 s |
| Output current tolerance, min./full load | ±5 % |
| Max. output current peak (non-repetitive) + max. peak output current | ≤ output current +15 % |
| Output LF current ripple (< 120 Hz) / Current ripple at full load | ±5 % |
| Output P_ST_LM (at full load) | ≤1 |
| Output SVM (at full load) | ≤0.4 |
| Max. output voltage | 200 V |
| Dimming range | 10–100 % |
| Mains surge capability (between L - N) | 6 kV |
| Mains surge capability (between L/N - PE) | 10 kV |
| Surge voltage at output side (against PE) | <1 kV |
| Type of protection | IP20 |
| Length | 150 mm |
| Width | 90 mm |
| Height | 37.5 mm |
| Lifetime | up to 100000 h |
| Guarantee | 5 years |
| Output mode | CC |
| Maximum output power [W] | 110 |
| Input voltage | 220 – 240 V |
| IP grade | IP20 |
| Warranty [years] | 5 |
| THD | <10 % |
| Typ. efficiency at 230 V | 92 % |
| λ over full operating range (max.) | 0.98 |
| Dimensions L×W×H | 150 × 90 × 37.5 mm |
| Lifetime [h] | up to 100000 h |
| Product net weight | 0.362 kg |
| Interfaces and configuration | NFC |
| Dimming | Yes |
| Configuration method | NFC |
| Manufacturer note: Product description | Dimmable 110 W built-in constant current LED-Driver for basic, functional Streetlighting luminaires |
| Manufacturer note: Product description | For luminaires of protection class I and protection class II |
| Manufacturer note: Product description | Temperature protection as per EN 61347-2-13 C5e |
| Manufacturer note: Product description | In line with industry standards (high surge/burst, NFC programming, high Power Factor, long life-time) |
| Manufacturer note: Product description | Output current adjustable between 200 – 1,050 mA via NFC (pre-selected current 200 mA) |
| Manufacturer note: Product description | Autonomous dimming via driver in-built chronoSTEP functionality |
| Manufacturer note: Product description | Nominal lifetime up to 100,000 h |
| Manufacturer note: Product description | Wide operating window |
| Manufacturer note: Product description | 5 years guarantee + 3 years of warranty extension depending on operating conditions (conditions at https://www.tridonic.com/en/int/services/manufacturer-guarantee-conditions) |
| Manufacturer note: Interfaces | NFC for programming and configuration (single and multi packaging) |
| Manufacturer note: Interfaces | chronoSTEP3 V2 (astronomical midnight) for fixed reduction of the luminous flux in the night |
| Manufacturer note: Interfaces | u6Me2 for centrally programming the streetlights via mains from the cabinet |
| Manufacturer note: Interfaces | Terminal blocks: 45° push terminals |
| Manufacturer note: Functions | Adjustable output current in 1-mA-steps (NFC) |
| Manufacturer note: Functions | Programmable chronoSTEP: times and levels (NFC, U6Me2) – 1 profile programmable |
| Manufacturer note: Functions | Constant light output function (CLO) |
| Manufacturer note: Functions | Protective features |
| Manufacturer note: Functions | Intelligent Voltage Guard Plus (IVG+) |
| Manufacturer note: Benefits | Wide operating window (1 output) to cover different LED module combinations and several operating points of the luminaire |
| Manufacturer note: Benefits | NFC programming and current adjustment for easy configuration |
| Manufacturer note: Benefits | chronoSTEP drivers to be programmed "centrally" in the field from the cabinet via U6Me2 |
| Manufacturer note: Benefits | High surge protection: up to 10 kV |
| Manufacturer note: Benefits | Integrated ESD protection |
| Manufacturer note: Typical applications | Street- and Roadlighting, in line with European Street Lighting Standard EN-13201 |
Operating points
| Point | Output current | Min./Max. forward voltage | Typ. current consumption | Output power | Typ. power consumption | Ambient temperature ta | tc point max |
|---|---|---|---|---|---|---|---|
| 1 | 200.0 mA | 48 V; 157 V | 177 mA | 31.4 W | 36.9 W | -40–60 °C | 75.0 °C |
| 2 | 300.0 mA | 48 V; 157 V | 238 mA | 47.1 W | 52.1 W | -40–60 °C | 75.0 °C |
| 3 | 400.0 mA | 48 V; 157 V | 306 mA | 62.8 W | 68.2 W | -40–60 °C | 75.0 °C |
| 4 | 500.0 mA | 48 V; 157 V | 374 mA | 78.5 W | 84.2 W | -40–60 °C | 75.0 °C |
| 5 | 600.0 mA | 48 V; 157 V | 443 mA | 94.2 W | 100.4 W | -40–55 °C | 76.0 °C |
| 6 | 700.0 mA | 48 V; 157 V | 514 mA | 109.9 W | 116.9 W | -40–55 °C | 76.0 °C |
| 7 | 800.0 mA | 48 V; 137.5 V | 512 mA | 110 W | 116.4 W | -40–55 °C | 73.0 °C |
| 8 | 900.0 mA | 48 V; 122.2 V | 510 mA | 110 W | 116.2 W | -40–55 °C | 73.0 °C |
| 9 | 1050.0 mA | 48 V; 104.8 V | 514 mA | 110 W | 117 W | -40–55 °C | 73.0 °C |
The Vmin/Vmax and CC operating-window filter features represent the global envelope of all documented settings. The complete operating-point table defines the permitted voltage at each current setting.
Installation / application
Select LED modules by comparing their forward voltage and current with the operating window at the chosen setting. Maximum tc and permissible ambient temperature apply under the conditions stated for each operating point.
Additional information
Warranty and declared lifetime are subject to manufacturer conditions. Other family versions do not establish the contents of this article; assess its exact model designation and assigned photographs together.
Main source of information: www.tridonic.com
We make every effort to ensure that the information presented in this product description is complete, up to date and consistent with source documentation. However, product ranges and specifications may evolve and be updated, and some changes may not yet be reflected in our description. Inaccuracies or errors may also occur in the source documentation itself. If you have any doubts or notice an error, please contact us at bok@ledownia.pl.
zas_tridonic_87501194
Data sheet
- Power supply type
- Constant Current (CC)
- Rated power [W]
- 110
- Output Current of CC power supply [mA]
- 200-1050
- CC operating window
- 48-157
- Min. output voltage of led driver (CC)
- 48
- Max. output voltage of led driver (CC)
- 157
- Dimensions (L x W x H) [mm]
- 150 × 90 × 37.5 mm
- IP grade
- 20
- Length [mm]
- 150
- Width [mm]
- 90
- Height/thickness [mm]
- 37.5
- Warranty [years]
- 5
- Input voltage [V]
- 220-240
- Min. current of CC driver [mA]
- 200
- Max. current of CC driver [mA]
- 1050
- Power factor
- 0.98
