LED power supply Tridonic LC 28/100-700/40 DA Ti-W EXC
LED power supply Tridonic LC 28W 100-700mA 40V DA Ti-W EXC is a constant current LED driver rated up to 28 W. Values for individual settings are shown in the operating-point table. Documented interfaces and configuration methods: DALI.
LED power supply Tridonic LC 28/100-700/40 DA Ti-W EXC
560.00 PLN
Shipment in 8-10 working days
zas_tridonic_28005614
LED power supply Tridonic LC 28W 100-700mA 40V DA Ti-W EXC is a constant current LED driver rated up to 28 W. Values for individual settings are shown in the operating-point table. Documented interfaces and configuration methods: DALI.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
LED power supply Tridonic LC 28W 100-700mA 40V DA Ti-W EXC is a constant current LED driver in the Driver LC 28W 100-700mA 40V DA T EXC family. Official article number 28005614 identifies this physical version.
Key properties
Common and exact-article specifications are kept separate from operating points. Power, LED voltage, efficiency and temperatures may depend on settings and load; the complete multi-row manufacturer data is shown below.
Technical specifications
| Manufacturer article number | 28005614 |
|---|---|
| Manufacturer family | Driver LC 28W 100-700mA 40V DA T EXC |
| Manufacturer product group | in-track drivers |
| Supply voltage | 220 – 240 V |
| AC voltage range | 198 – 264 V |
| Mains frequency | 50 / 60 Hz |
| Input current | 150 mA |
| Power Consumption | 33 W |
| Typ. efficiency at 230 V | 86 % |
| λ over full operating range (max.) | 0.96 |
| THD at 230V, full load | <20 % |
| Starting time | <0.5 s |
| Turn off time | ≤0.5 s |
| Output current tolerance, min./full load | ±5 % |
| Max. repetitive output peak current | 735 mA |
| Output LF current ripple (< 120 Hz) / Current ripple at full load | ±0.2 % |
| Output P_ST_LM (at full load) | ≤1 |
| Output SVM (at full load) | ≤0.4 |
| Max. output voltage | 60 V |
| Dimming range | 0.1–100 % |
| Mains surge capability (between L - N) | 1 kV |
| Ambient temperature ta | 25 °C |
| Type of protection | IP20 |
| Length | 350 mm |
| Width | 28.4 mm |
| Height | 13.8 mm |
| Lifetime | up to 50000 h |
| Guarantee | 5 years |
| Output mode | CC |
| Maximum output power [W] | 28 |
| Input voltage | 220 – 240 V |
| IP grade | IP20 |
| Warranty [years] | 5 |
| THD | <20 % |
| Typ. efficiency at 230 V | 86 % |
| λ over full operating range (max.) | 0.96 |
| Dimensions L×W×H | 350 × 28.4 × 13.8 mm |
| Lifetime [h] | up to 50000 h |
| Product net weight | 0.11 kg |
| Interfaces and configuration | DALI |
| Dimming / control | DALI |
| Dimming | Yes |
| short_circuit_protection | Yes |
| overload_protection | Yes |
| no_load_protection | Yes |
| Manufacturer note: Product description | Dimmable constant current / in-track LED driver |
| Manufacturer note: Product description | Completely in-track, enabling a true no-compromise design |
| Manufacturer note: Product description | Optional accessory for mounting the luminaire head |
| Manufacturer note: Product description | Dimming range 1 to 100 % (min. 3.5 mA) |
| Manufacturer note: Product description | For luminaires of protection class II |
| Manufacturer note: Product description | Temperature protection as per EN 61347-2-13 C5e |
| Manufacturer note: Product description | Selectable fixed output current via DIP switch 100 and 700 mA (pre-selected current 100 mA) or DALI |
| Manufacturer note: Product description | Max. output power 28 W |
| Manufacturer note: Product description | Up to 86 % efficiency |
| Manufacturer note: Product description | Power input on stand-by < 0.5 W |
| Manufacturer note: Product description | Nominal lifetime up to 100,000 h |
| Manufacturer note: Product description | 5 years guarantee (conditions at https://www.tridonic.com/en/int/services/manufacturer-guarantee-conditions) |
| Manufacturer note: Housing properties | Casing: polycarbonate, black, white or grey |
| Manufacturer note: Housing properties | Type of protection IP20 |
| Manufacturer note: Interfaces | Terminal blocks: 45° push terminals |
| Manufacturer note: Functions | Overtemperature protection |
| Manufacturer note: Functions | Overload protection |
| Manufacturer note: Functions | Short-circuit protection |
| Manufacturer note: Functions | No-load protection |
| Manufacturer note: Functions | Burst protection voltage 2 kV |
| Manufacturer note: Functions | Surge protection voltage 1 kV (L to N) |
| Manufacturer note: Typical applications | For spot light in retail and hospitality application |
Operating points
| Point | Output current | Min./Max. forward voltage | Output power | Ambient temperature ta | tc point max | Resistor / I-out select |
|---|---|---|---|---|---|---|
| 1 | 100.0 mA | 12 V; 40 V | 4 W | -20–35 °C | 85.0 °C | 1=off / 2=off / 3=off / 4=off |
| 2 | 200.0 mA | 12 V; 40 V | 8 W | -20–35 °C | 85.0 °C | 1=off / 2=off / 3=on / 4=off |
| 3 | 300.0 mA | 12 V; 40 V | 12 W | -20–35 °C | 85.0 °C | 1=off / 2=on / 3=off / 4=off |
| 4 | 400.0 mA | 12 V; 40 V | 16 W | -20–35 °C | 85.0 °C | 1=on / 2=off / 3=off / 4=off |
| 5 | 500.0 mA | 12 V; 40 V | 20 W | -20–35 °C | 85.0 °C | 1=on / 2=off / 3=on / 4=on |
| 6 | 600.0 mA | 12 V; 40 V | 24 W | -20–35 °C | 85.0 °C | 1=on / 2=on / 3=off / 4=off |
| 7 | 700.0 mA | 12 V; 40 V | 28 W | -20–35 °C | 85.0 °C | 1=on / 2=on / 3=on / 4=on |
The Vmin/Vmax and CC operating-window filter features represent the global envelope of all documented settings. The complete operating-point table defines the permitted voltage at each current setting.
Installation / application
Select LED modules by comparing their forward voltage and current with the operating window at the chosen setting. Maximum tc and permissible ambient temperature apply under the conditions stated for each operating point.
Additional information
Warranty and declared lifetime are subject to manufacturer conditions. Other family versions do not establish the contents of this article; assess its exact model designation and assigned photographs together.
Main source of information: www.tridonic.com
We make every effort to ensure that the information presented in this product description is complete, up to date and consistent with source documentation. However, product ranges and specifications may evolve and be updated, and some changes may not yet be reflected in our description. Inaccuracies or errors may also occur in the source documentation itself. If you have any doubts or notice an error, please contact us at bok@ledownia.pl.
zas_tridonic_28005614
Data sheet
- Power supply type
- Constant Current (CC)
- Rated power [W]
- 28
- Output Current of CC power supply [mA]
- 100-700
- CC operating window
- 12-40
- Min. output voltage of led driver (CC)
- 12
- Max. output voltage of led driver (CC)
- 40
- Dimming / Control
- DALI
- Dimensions (L x W x H) [mm]
- 350 × 28.4 × 13.8 mm
- IP grade
- 20
- Length [mm]
- 350
- Width [mm]
- 28.4
- Height/thickness [mm]
- 13.8
- Warranty [years]
- 5
- Input voltage [V]
- 220-240
- Min. current of CC driver [mA]
- 100
- Max. current of CC driver [mA]
- 700
- Power factor
- 0.96
