Mean Well HDR-100-15 92W 15V LED Power Supply

Name: Mean Well HDR-100-15 92W 15V LED Power Supply
Brand: Mean Well
SKU: tm_HDR-100-15
Price: 130.07 PLN
Availability: InStock

Minimum order quantity: 1. Order in multiples of 1.

130.07 PLN

Shipment in 1-2 business days

Reference: tm_HDR-100-15

Mean Well HDR-100-15 is a 92 W, 15 V DC constant-voltage power supply for mounting on TS-35/7.5 or TS-35/15 DIN rail.

Volume discounts

Quantity	Discounted price
10+	121.94 PLN

Quantity

Delivery

1-3 dni (PL), 3-10 dni (non-PL)

Return Policy

14 days

HDR-100-15 – full product specification

Mean Well HDR-100-15 is a HDR-100-series power supply rated at 92 W. The parameters below come from the exact official manufacturer datasheet.

The supply operates in CV mode. Its output can be set across 13.5 V–18 V, and the enclosure mounts on TS-35/7.5 or TS-35/15 DIN rail.

Cooling	free-air convection
Dimensions	70 × 90 × 54.5 mm
Document revision	HDR-100-SPEC 2026-04-03
Typical efficiency	89 %
hold_up_time	230 vac ms: 30; 115 vac ms: 12
Input frequency	47–63 Hz
Input range	85–264 VAC / 120–370 VDC
Inrush current	35 A
Mounting	TS-35/7.5 or TS-35/15 DIN rail
Operating temperature	-30–70 °C
Rated current	6130 mA
Operating mode	Constant Voltage (CV)
Maximum adjusted voltage	18 V
Minimum adjusted voltage	13.5 V
Adjustment range by LPS condition	LPS 15–17 V; non-LPS 13.5–18 V
Output voltage	15 V
Over-voltage protection range	18.8–22.5 V
Over-voltage protection	Yes
Rated power	92 W
Manufacturer warranty	3 years
Weight	0.27 kg
Withstand voltage	4 kVAC
