Mean Well PLC-100-36 95.4 W CV+CC LED driver

Name: Mean Well PLC-100-36 95.4 W CV+CC LED driver
Brand: Mean Well
SKU: tm_PLC-100-36
Price: 195.11 PLN
Availability: InStock

Minimum order quantity: 1. Order in multiples of 1.

195.11 PLN

Shipment in 1-2 business days

Reference: tm_PLC-100-36

Mean Well PLC-100-36 is a 95.4 W CV+CC LED driver with a 27 V–36 V constant-current region.

Delivery

1-3 dni (PL), 3-10 dni (non-PL)

Return Policy

14 days

PLC-100-36 – full product specification

Mean Well PLC-100-36 is a PLC-100-series power supply rated at 95.4 W. The parameters below come from the exact official manufacturer datasheet.

The driver combines voltage regulation and current limiting; its constant-current region is 27 V–36 V DC.

Cooling	free-air convection
Dimensions	200.5 × 69.5 × 35 mm
Document revision	PLC-100-SPEC 2026-06-15
Typical efficiency	88 %
hold_up_time	230 vac ms: 60; 115 vac ms: 16
Input frequency	47–63 Hz
Input range	90–264 VAC / 127–370 VDC
Inrush current	40 A
Operating temperature	-30–50 °C
Rated current	2650 mA
Operating mode	Constant voltage + constant current (CV+CC)
CC-region maximum voltage	36 V
CC-region minimum voltage	27 V
Output voltage	36 V
Over-voltage protection range	39–48 V
Over-voltage protection	Yes
Short-circuit protection	Yes
Rated power	95.4 W
Manufacturer warranty	2 years
Weight	0.52 kg
