LED power supply Tridonic LC 65W 200-350mA | LEDownia.pl

LED power supply | Tridonic LC 65W 200-350mA 210V flexC lp SNC4

Name: LED power supply | Tridonic LC 65W 200-350mA 210V flexC lp SNC4
Brand: Tridonic
SKU: zas_tridonic_87500995
Price: 82.11 PLN
Availability: InStock

82.11 PLN

Shipment in 1-2 business days

Category: Constant Current (CC)

Reference: zas_tridonic_87500995

Tridonic LC 65/200-350/210 flexC lp SNC4 is a linear constant current LED power supply with up to 65.1 W output. It offers selectable output current 200–350 mA via DIP switch. Ideal for linear and downlight luminaires, it delivers efficiency up to 93.5% and a lifetime up to 100,000 h.

Delivery

1-3 dni (PL), 3-10 dni (non-PL)

Return Policy

14 days

Description
Product Details

Technical data of Tridonic LC 65/200-350/210 flexC lp SNC4 LED power supply

Brand	Tridonic
Series	Essence, linear fixed output non-SELV
Model / index	LC 65/200-350/210 flexC lp SNC4 (87500995)
Device type	Constant current LED power supply for luminaire integration
Maximum output power	65.1 W
Output power range	18 – 65.1 W
Output current range	200 / 250 / 300 / 350 mA (DIP)
Preset output current	350 mA
Output voltage range	90 – 210 V DC (for 350 mA 90 – 186 V)
Rated input voltage	220 – 240 V AC
AC voltage range	198 – 264 V AC
DC voltage range	176 – 280 V DC
Mains frequency	0 / 50 / 60 Hz
Max. input current	0.32 A at 230 V, full load
Typical efficiency	up to 93.5%
Power factor	0.8 – 0.98
Output current ripple	< ±5%
THD	< 10% at full load
Start-up time	≤ 0.5 s (AC), ≤ 0.6 s (DC)
Turn off time	≤ 0.5 s
Ambient temperature ta	-20 ... +60 °C
Storage temperature	-40 ... +80 °C
Service life	up to 100,000 h
Protection class	For class I luminaires, IP20
Protections	Overload, short circuit, no-load, overtemperature
Housing material	Metal, white
Dimensions	230 x 30 x 21 mm
Mounting hole spacing	218 mm
Weight	0.152 kg
Maximum tc point	up to 85 °C (current dependent)
Manufacturer warranty	5 years
Product website	http://www.tridonic.com/87500995

Product description Tridonic LC 65/200-350/210 flexC lp SNC4

This LED power supply is designed for linear and downlight luminaires in professional installations. It is intended for inbuilt use in class I luminaires. The slim ML300 housing offers robust mechanical protection and supports efficient thermal management. IP20 protection class makes it suitable for indoor applications.

The power supply provides selectable constant current outputs from 200 to 350 mA. Current is set via a DIP switch and requires mains to be switched off. This flexibility allows the same device to match various LED modules and string configurations. Maximum output power of 65.1 W supports long linear systems and powerful ceiling luminaires.

High efficiency up to 93.5% reduces energy losses and heat generation. Low output ripple keeps light stable and comfortable for users. Flicker metrics P_ST_LM and SVM comply with modern lighting comfort requirements. This makes the power supply suitable for offices, schools and commercial spaces.

LED power supply with complete protection features

Integrated protection circuits cover overload, short circuit and no-load situations. The power supply also includes temperature monitoring with automatic shutdown. When the unit cools down, it restarts automatically and returns to normal operation. These features increase reliability of the whole luminaire.

The power supply can run on AC mains as well as DC and pulsed DC emergency systems. It is suitable for use in central battery installations according to relevant standards. Low leakage current and robust surge protection support reliable operation in demanding projects.

LED power supply for linear luminaires and OEM projects

The long, low-profile housing with 218 mm fixing distance fits many linear luminaires. Push-wire terminals enable fast and secure wiring on production lines. Short connection leads and proper separation from mains wiring help achieve good EMC performance. The device is tested with many switching cycles, ideal for sensor or control based operation.

Lifetime up to 100,000 hours at correct temperature conditions reduces maintenance costs. The Tridonic LC 65/200-350/210 flexC lp SNC4 LED power supply is a reliable choice for OEM luminaire manufacturers. It supports efficient, long-lasting LED lighting in corridors, offices, retail and public buildings.
