LED power supply | Tridonic LC 10W 200-350mA flexC lp SNC4

Name: LED power supply | Tridonic LC 10W 200-350mA flexC lp SNC4
Brand: Tridonic
SKU: zas_tridonic_28004119
Price: 55.28 PLN
Availability: InStock

55.28 PLN

Shipment in 1-2 business days

Category: Constant Current (CC)

Reference: zas_tridonic_28004119

Tridonic LC 10W 200-350mA flexC lp SNC4 is a compact constant current LED power supply. Output current is selectable from 200–350 mA using DIP switches. Maximum output power is 10.2 W with efficiency up to 83.5%. The power supply offers overload, short circuit and no load protection. Designed for class I and II luminaires, especially linear and recessed solutions.

Delivery

1-3 dni (PL), 3-10 dni (non-PL)

Return Policy

14 days

Description
Product Details

Technical data of LED power supply Tridonic LC 10W 200-350mA flexC lp SNC4

Manufacturer	Tridonic
Series	essence, flexC lp SNC4
Model	LC 10/200-350/29 flexC lp SNC4
Article number	28004119
Type	Constant current LED power supply, SELV, inbuilt
Maximum output power	10.2 W
Output power range	2.8 – 10.2 W
Output current range	200 / 250 / 300 / 350 mA (DIP selectable)
Output current tolerance	± 7.5%
Minimum output voltage	14 V
Maximum output voltage	29 V (U-OUT max. 37 V)
Typical efficiency	up to 83.5%
Power factor	0.94 (230 V, full load)
THD	< 20%
Output ripple current	< ±5% (< 120 Hz)
Rated supply voltage	220 – 240 V AC
AC voltage range	198 – 264 V
DC voltage range	176 – 280 V
Mains frequency	0 / 50 / 60 Hz
Input current (230 V)	0.056 A
Start-up time	≤ 0.5 s (AC), ≤ 0.6 s (DC)
Turn off time	≤ 0.5 s
Protection type	IP20
Housing material	Polycarbonate, white
Dimensions	145 x 22 x 21 mm
Fixing hole spacing	132.8 mm
Ambient temperature ta	-20 … +60 °C
Maximum tc temperature	up to 85 °C (depending on current)
Storage temperature	-40 … +80 °C
Rated lifetime	up to 100,000 h
Manufacturer warranty	5 years
Temperature protection	EN 61347-2-13 C5e
Protections	overload, short circuit, no load operation
Luminaire protection class	I and II
Standards	EN 55015, EN 61000-3-2, EN 61000-3-3, EN 61347-1, EN 61347-2-13, EN 61547, EN 62384, EN 50172, EN 60598-2-22
Product website	http://www.tridonic.com/28004119

LED power supply Tridonic – compact size and high reliability

This LED power supply Tridonic LC 10W 200-350mA flexC lp SNC4 is a very good choice for slim linear luminaires. The narrow 145 mm housing simplifies integration in profiles and recessed channels. Lightweight white polycarbonate ensures mechanical stability and easy handling during installation.

The unit provides constant current with four selectable levels. Available settings are 200, 250, 300 and 350 mA. Selection is done via DIP switches that must be adjusted with mains disconnected. This makes matching the power supply to the LED module straightforward and safe.

Efficiency up to 83.5% and a power factor of 0.94 help reduce energy losses. Output ripple remains below ±5%, which supports stable light output and visual comfort. The power supply is suitable for use in emergency lighting systems. Compliance with EN 50172 and EN 60598-2-22 enables integration in central battery installations.

LED power supply – safety, protection and long lifetime

The power supply integrates comprehensive electronic protection functions. It protects against output short circuit, overload and operation without connected LED modules. Once the fault is cleared, the unit automatically returns to normal operation. This behaviour simplifies maintenance in commercial and industrial projects.

The IP20 housing is designed for use inside luminaires and dry indoor locations. As an inbuilt controlgear it fits perfectly in linear luminaires, downlights and trunking systems. Maximum tc up to 85 °C allows operation in demanding thermal conditions when luminaire design is correct.

The rated lifetime reaches up to 100,000 hours, assuming proper thermal management. Tridonic backs this LED power supply with a 5 year manufacturer warranty. These parameters make it a robust choice for general lighting, office projects and emergency systems. Installers and designers gain a reliable component with predictable performance and easy configuration.
