LED power supply | Philips CertaDrive 30W 350mA 50–85V 230V EL led driver

Name: LED power supply | Philips CertaDrive 30W 350mA 50–85V 230V EL led driver
Brand: Philips
SKU: zas_philips_929003450280
Price: 97.55 PLN
Availability: InStock

97.55 PLN

Shipment in 1-2 business days

Category: Constant Current (CC)

Reference: zas_philips_929003450280

LED power supply Philips CertaDrive 30W 0.35A (50–85V) for linear luminaires. Typical efficiency around 88%, low ripple, PF ≥ 0.95 and rated lifetime up to 50,000 h. Perfect for office and retail fixtures.

Volume discounts

Quantity	Discounted price
5+	89.42 PLN
10+	81.29 PLN

Quantity

Wishlist

Compare

Delivery

1-3 dni (PL), 3-10 dni (non-PL)

Return Policy

14 days

Description
Product Details

LED power supply

Philips CertaDrive 30W 0.35A

Technical data (summary)

Parameter	Value
Output power	approx. 17.5–29.75 W (nominal 30 W)
Output current	350 mA (0.35 A), constant current
Output voltage range	50–85 V DC
Input voltage	220–240 V AC, 50–60 Hz (operating range as per datasheet)
Efficiency	around 88 % (typical at full load)
Power factor	≥ 0.95 at rated power
Ambient temperature (Ta)	-20…+50 °C (subject to T_case limits)
Rated lifetime	up to 50 000 h at specified T_case-life
Protection rating	IP20, Class I
Housing dimensions	approx. 168 × 30 × 21 mm
Operating mode	constant current, non-dimmable

Philips CertaDrive 30W 0.35A – reliable CC LED power supply for linear luminaires

Philips CertaDrive 30W 0.35A 85V 230V EL is a constant current LED power supply designed for linear and panel luminaires in office, commercial and industrial applications. A fixed output current of 350 mA and a wide output voltage window of 50–85 V allow you to supply standard linear LED modules with a system power of around 30 W, ensuring stable and efficient lighting.

The CertaDrive range offers a very good balance between cost and performance – high efficiency, low current ripple and a rated lifetime of 50 000 h make this driver a solid choice for volume luminaires where reliability and consistent performance are critical.

Key features of the CertaDrive 30W 0.35A led power supply

Constant current LED driver – 350 mA fixed output current.
Wide output voltage window: 50–85 V DC (approx. 17.5–29.75 W output power).
Mains supply 220–240 V AC, 50–60 Hz with DC operation capability.
Typical efficiency around 88 % at full load.
High power factor PF ≥ 0.95 at nominal load.
Low output ripple – for comfortable, practically flicker-free light.
Rated lifetime up to 50 000 h at specified T_case-life.
Compact housing for linear luminaires: approx. 168 × 30 × 21 mm.
IP20 rating, indoor use, Class I.
Integrated protections: short-circuit, overload, over-voltage and over-temperature (see datasheet for limits).
Fixed current, non-dimmable – ideal for standard, cost-optimised luminaire designs.

Typical applications

The CertaDrive 30W 0.35A driver is intended mainly for:

linear LED luminaires in offices, corridors, warehouses and retail spaces,
LED panels and grid luminaires,
surface-mounted and recessed fixtures with linear LED modules,
retrofit projects replacing fluorescent systems with LED.

With its constant 350 mA output and 50–85 V window, it is a perfect match for linear modules around 20–30 W where good efficacy and simple integration are required.

Installation notes

The driver is a non-isolated design. All applicable safety rules and insulation requirements for accessible parts of the luminaire must therefore be strictly followed. Installation should be carried out by a qualified electrician in accordance with the Philips datasheet and local regulations.
