Mean Well APC-12-700 12.6W 700mA 9–18V Constant Current (CC) LED driver
Mean Well APC-12-700 is a 12.6 W constant-current LED driver rated at 700 mA, with a 9–18 V DC output voltage range. IP rating IP42.
Mean Well APC-12-700 12.6W 700mA 9–18V Constant Current (CC) LED driver
Minimum order quantity: 1. Order in multiples of 1.
27.63 PLN
Shipment in 1-2 business days
tm_APC-12-700
Mean Well APC-12-700 is a 12.6 W constant-current LED driver rated at 700 mA, with a 9–18 V DC output voltage range. IP rating IP42.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
APC-12-700 – full product specification
Mean Well APC-12-700 is an LED power supply from the APC-12 series with a 12.6 W rated output. The verified manufacturer datasheet data below supports correct circuit and operating-condition selection.
Selection and output
Select this driver for an LED circuit rated at 700 mA. The required operating voltage of the complete powered circuit must remain within 9–18 V DC, while the connected load must also remain within the rated output power.
Input and efficiency
The specified input range is 90–264 VAC / 127–370 VDC. The input frequency range is 47–63 Hz. Manufacturer-specified typical efficiency is 80 %.
Full technical specifications
| Manufacturer | Mean Well |
|---|---|
| Series | APC-12 |
| Model | APC-12-700 |
| Operating mode | Constant Current (CC) |
| Rated power | 12.6 W |
| Output current | 700 mA |
| Output voltage range | 9–18 V DC |
| Input voltage range | 90–264 VAC / 127–370 VDC |
| Input frequency | 47–63 Hz |
| Typical efficiency | 80 % |
| Current accuracy | 8 % |
| AC input current | 0.35 A (115 V AC); 0.2 A (230 V AC) |
| Inrush current | 70 A |
| Leakage current | 0.25 mA |
| Over-voltage protection range | 20.7–24.3 V |
| Short-circuit protection | Yes |
| Over-voltage protection | Yes |
| Fully isolated enclosure | Yes |
| Enclosure material | plastic |
| Cooling | free-air convection |
| Insulation resistance | 100 MΩ |
| IP rating | IP42 |
| Operating temperature | -30–70 °C |
| Dimensions (L × W × H) | 77 × 40 × 29 mm |
| Technical weight | 0.08 kg |
| Manufacturer warranty | 2 years |
Protection and construction
- Short-circuit protection: Yes
- Over-voltage protection: Yes
- Over-voltage protection range: 20.7–24.3 V
- Fully isolated enclosure: Yes
- Enclosure material: plastic
- Cooling: free-air convection
- Insulation resistance: 100 MΩ
- IP rating: IP42
Operating conditions and mechanical data
Operating temperature: -30–70 °C; Dimensions (L × W × H): 77 × 40 × 29 mm; Technical weight: 0.08 kg; Manufacturer warranty: 2 years.
Manufacturer datasheet
The complete source specification is available directly from the manufacturer: Official Mean Well datasheet — APC-12-SPEC 2025-12-12.
tm_APC-12-700
Data sheet
- Power supply type
- Constant Current (CC)
- Rated power [W]
- 10,1-15
- Output Current of CC power supply [mA]
- 700
- CC operating window
- 9-18
- Min. output voltage of led driver (CC)
- 9
- Max. output voltage of led driver (CC)
- 18
- Dimensions (L x W x H) [mm]
- 77/40/29
- IP grade
- 42
- Case type of power supply
- Isolated / secured
- Case material
- Plastic
- Length [mm]
- 77
- Grounding
- No
- Width [mm]
- 40
- Height/thickness [mm]
- 29
- Warranty [years]
- 2
- Input voltage [V]
- 90-264
- Interface
- Integrated input and output cable
Specific References
- MPN
- APC-12-700
