Mean Well LCM-40TW 40W 500–1050mA Constant Current (CC) LED driver
Mean Well LCM-40TW is a 40 W CC LED driver with selectable current across 500 mA–1050 mA; the current-to-voltage relation follows the manufacturer table.
Mean Well LCM-40TW 40W 500–1050mA Constant Current (CC) LED driver
Minimum order quantity: 1. Order in multiples of 1.
170.72 PLN
Shipment in 1-2 business days
tm_LCM-40TW
Mean Well LCM-40TW is a 40 W CC LED driver with selectable current across 500 mA–1050 mA; the current-to-voltage relation follows the manufacturer table.
Delivery
1-3 dni (PL), 3-10 dni (non-PL)
Privacy Policy
Return Policy
14 days
LCM-40TW – full product specification
Mean Well LCM-40TW is a LCM-40TW-series power supply rated at 40 W. The parameters below come from the exact official manufacturer datasheet.
Selectable CC current
Current is selected across 500 mA–1050 mA; exact current-to-voltage pairs follow the official model table.
Full technical specifications
| DALI control | Yes |
|---|---|
| PUSH dimming | Yes |
| current_selection | 500 mA: 27–50 V; 600 mA: 25–50 V; 700 mA: 20–50 V; 800 mA: 20–50 V; 900 mA: 20–44 V; 1050 mA: 20–38 V |
| Maximum adjustable current | 1050 mA |
| Minimum adjustable current | 500 mA |
| Operating mode | Constant Current (CC) |
| Rated power | 40 W |
Manufacturer datasheet
Complete source specification: official Mean Well datasheet.
tm_LCM-40TW
Data sheet
- Power supply type
- Constant Current (CC)
- Rated power [W]
- 30,1-60
- Min. current of CC driver [mA]
- 500
- Max. current of CC driver [mA]
- 1050
Specific References
- EAN13
- 4711287510262
- MPN
- LCM-40TW
