Mean Well LCM-25KN 25.2W 350–1050mA Constant Current (CC) LED driver

Minimum order quantity: 1. Order in multiples of 1.
170.72 PLN
Shipment in 1-2 business days
Constant Current (CC)
tm_LCM-25KN

Mean Well LCM-25KN is a 25.2 W CC LED driver with selectable current across 350 mA–1050 mA; the current-to-voltage relation follows the manufacturer table.

Quantity
Wishlist
Compare
  Delivery

1-3 dni (PL), 3-10 dni (non-PL)



Privacy Policy

  Return Policy

14 days

LCM-25KN – full product specification

Mean Well LCM-25KN is a LCM-25KN-series power supply rated at 25.2 W. The parameters below come from the exact official manufacturer datasheet.

Selectable CC current

Current is selected across 350 mA–1050 mA; exact current-to-voltage pairs follow the official model table.

Full technical specifications

DALI controlYes
KNX controlYes
PUSH dimmingYes
current_ripple_pct5 %
current_selection350 mA: 6–54 V; 500 mA: 6–50 V; 600 mA: 6–42 V; 700 mA: 6–36 V; 900 mA: 6–28 V; 1050 mA: 6–24 V
Dimensions105 × 68 × 23 mm
Document revisionLCM-25KN-SPEC 2026-02-09
Input frequency47–63 Hz
Input range180–277 VAC / 220–380 VDC
Inrush current20 A
Insulation resistance100 MΩ
Maximum adjustable current1050 mA
Minimum adjustable current350 mA
Operating modeConstant Current (CC)
Short-circuit protectionYes
Rated power25.2 W
Manufacturer warranty3 years
Weight0.173 kg

Manufacturer datasheet

Complete source specification: official Mean Well datasheet.

tm_LCM-25KN

Data sheet

Power supply type
Constant Current (CC)
Rated power [W]
20,1-30
Length [mm]
105
Width [mm]
68
Height/thickness [mm]
23
Warranty [years]
3
Input voltage [V]
180-277
Min. current of CC driver [mA]
350
Max. current of CC driver [mA]
1050

Specific References

EAN13
4711287461304
MPN
LCM-25KN
